Hua Heng HY-6000V Intelligent Vibration Monitoring Protection Device for Industrial Equipment Safety Control

Name: Hua Heng HY-6000V Intelligent Vibration Monitoring Protection Device for Industrial Equipment Safety Control
Brand: OUTER ELECTRONIC TECHNOLOGY (HK) LIMITED
SKU: HY-6000V
Price: 210.00 USD
Availability: InStock

Brand Name:	Hua Heng
Model Number:	HY-6000V
MOQ:	1
Price:	Negotiation

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Packaging Details:

New original box

Highlight:

Hua Heng HY-6000V vibration monitoring device

industrial equipment safety control relay

intelligent vibration protection device

Product Description

Hua Heng HY-6000V Intelligent Vibration Monitoring Protection Device

The HY-6000V intelligent vibration monitoring and protection device is a multi-channel combined intelligent instrument designed for industrial equipment safety control in power, steel, rail transit, building materials, chemical, and other critical industries.

Key Features

Modular structure with freely configurable channel combinations
High intelligence with full panel parameter settings and automatic memory/query of maximum measurement values
Suitable for long-term online monitoring with easy installation and no on-site maintenance required
Each module provides 4-20 mA current analog output and secondary alarm switch output
High-performance switching power supply with independent microprocessors in each module
Advanced signal filtering and isolation for strong anti-interference capability and stable performance

Technical Specifications

Parameter	Specification
Measurement Range	Amplitude: 0-500 μm (peak to peak) Intensity: 0-500 mm/s (true effective value)
Frequency Range	5-3 KHz
Input Signal	VS series vibration velocity sensor (absolute vibration) CWY-DO series Φ8mm eddy current sensor (relative vibration)
Measurement Accuracy	Level 0.5, linear error ≤±0.5%
Display Mode	LED or LCD display
Output Signals	4-20 mA (load resistance ≤850 Ω) BUF signal output for waveform analysis RS485 communication with Modbus RTU protocol Switching output: DC 27V/2A or AC 250V/5A
Operating Environment	-40℃ to 65℃, relative humidity ≤95% (non-condensing)
Supply Voltage	AC 85V-265V or DC 100V-360V
Installation Method	Perforated disc installation

Industrial Applications

The HY-6000V supports machinery safety, operational reliability, and efficient equipment management in critical industrial applications including energy, manufacturing, petrochemical, and other fields where equipment reliability is essential.

Benefits

This intelligent monitoring device enables early detection of potential mechanical issues, supports predictive maintenance strategies, reduces unexpected downtime, enhances production stability, and improves overall operational safety and asset performance management.
