Hua Heng HY-3V Vibration Analysis Protection Unit | Intelligent Machine Health Monitoring Device

Name: Hua Heng HY-3V Vibration Analysis Protection Unit | Intelligent Machine Health Monitoring Device
Brand: OUTER ELECTRONIC TECHNOLOGY (HK) LIMITED
SKU: HY-3V
Price: 210.00 USD
Availability: InStock

Brand Name:	Hua Heng
Model Number:	HY-3V

Detail Information

Product Description

Detail Information

Place of Origin:

China

Highlight:

Hua Heng HY-3V vibration analysis unit

intelligent machine health monitoring device

electronic control relay with warranty

Product Description

Hua Heng HY-3V Vibration Analysis Protection Unit

The Hua Heng HY-3V Vibration Analysis Protection Unit is an intelligent machine health monitoring device designed for continuous monitoring and protection of large rotating machinery. This professional industrial solution combines advanced digital processing technology with practical application experience to provide reliable equipment monitoring and protection.

Technical Specifications

Parameter	Specification
Measurement Range - Amplitude	0-500 μm (peak to peak)
Measurement Range - Intensity	0-50.0 mm/s (true effective value)
Frequency Range	5-3000 Hz
Input Signal	VS series vibration speed sensor (absolute vibration) CWY-DO - Φ8mm eddy current sensor (relative vibration)
Measurement Accuracy	Level 0.5, linear error ≤ ±0.5%
Display Mode	LED or LCD display
Output Signals	4-20mA current output (load resistance ≤850Ω) TBUF signal output for waveform analysis RS485 communication with Modbus RTU protocol Switching output: DC 27V/2A or AC250V/5A
Operating Environment	-40℃ to 65℃, relative humidity ≤95% (non-condensing)
Power Supply	AC 85V-265V or DC 100V-360V

Installation Options

Perforated Disc Installation: External dimensions: 160mm × 92mm × 210mm (W×H×D)
Hole size: 152+0.5mm × 76+0.5mm
Wall Mounted Installation: Dimensions: 290mm × 210mm × 75mm (W×H×T)
Installation dimensions: 110mm × 260mm
Fixed holes: 4×4mm

Key Features & Benefits

Advanced high-performance embedded chips and digital processing technology
Dual-function measurement of vibration displacement and velocity signals
Comprehensive anti-interference processing for stable performance in harsh environments
Power on/off detection with alarm and shutdown output circuit protection
Configurable delay output (0-99 seconds) to suppress false alarms
Universal power supply compatibility without conversion equipment
Easy parameter configuration via panel buttons
Suitable for long-term online monitoring applications

Application Benefits

The HY-3V supports proactive maintenance strategies by enabling early detection of potential machinery problems, reducing unexpected downtime, and extending equipment service life. Its intelligent monitoring capabilities help maintenance teams make informed decisions, improve operational confidence, and enhance overall system performance in energy, manufacturing, and industrial automation environments.

This vibration analysis protection unit represents Hua Heng's commitment to developing reliable, innovative monitoring solutions that strengthen equipment management and create safer, more efficient industrial operations through advanced condition monitoring technology.
