Hua Heng HY-5V Intelligent Vibration Analysis Monitor | Machinery Condition Protection Device

Name: Hua Heng HY-5V Intelligent Vibration Analysis Monitor | Machinery Condition Protection Device
Brand: OUTER ELECTRONIC TECHNOLOGY (HK) LIMITED
SKU: HY-5V
Price: 210.00 USD
Availability: InStock

Brand Name:	Hua Heng
Model Number:	HY-5V
MOQ:	1
Price:	Negotiation

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Packaging Details:

New original box

Highlight:

Hua Heng HY-5V vibration monitor

machinery condition protection device

intelligent vibration analysis monitor

Product Description

Hua Heng HY-5V Intelligent Vibration Analysis Monitor | Machinery Condition Protection Device

The Hua Heng HY-5V Intelligent Vibration Analysis Monitor is an advanced machinery protection solution designed to support reliable equipment operation through intelligent condition monitoring. Developed for industrial environments where equipment stability and safety are essential, this device helps users better understand machine operating conditions and improve maintenance efficiency.

Technical Specifications

Measurement Range: Amplitude: 0-500 μm (peak to peak); Intensity: 0-50.0mm/s (true effective value)
Frequency Range: 5-3000Hz
Input Signal: VS series vibration speed sensor (measuring absolute vibration of bearing shell); CWY-DO - Φ8mm eddy current sensor (measuring relative vibration of shaft)
Measurement Accuracy: Level 0.5, linear error ≤±0.5%
Display Mode: LED or LCD display
Output Signal: Current output: 4-20mA (load resistance ≤850Ω); TBUF signal output (waveform analysis); RS485 communication output: Modbus RTU communication protocol; Switching output: DC 27V/2A or AC250V/5A
Operating Environment: -40℃~65℃, relative humidity ≤95% (non-condensing)
Power Supply: AC 85V~265V or DC 100V~360V

Installation Options

Installation Type	Dimensions	Mounting Details
Perforated Disc Installation	160mm × 92mm × 210mm (W×H×D)	Hole size: 152+0.5mm × 76+0.5mm
Wall Mounted Installation	290mm × 210mm × 75mm (W×H×T)	Installation dimensions: 110mm × 260mm; Fixed hole: 4×4mm

Key Features

• Advanced digital processing technology with high-performance embedded chips

• Dual-function measurement of vibration displacement and velocity signals

• Comprehensive anti-interference processing for stable performance in harsh environments

• Power on/off detection with alarm and shutdown output circuit protection

• Configurable shutdown signal delay output (0-99 seconds) to prevent false alarms

• Universal power supply compatibility without conversion equipment

• Easy parameter configuration via panel buttons

Applications & Benefits

The HY-5V Intelligent Vibration Analysis Monitor provides effective monitoring capabilities that help detect changes in machinery behavior, allowing operators to take preventive measures and reduce the risk of unexpected failures. It supports condition-based monitoring and improves awareness of machinery performance.

This device is suitable for applications across industries such as power generation, manufacturing, energy systems, and other industrial fields where machinery reliability is a priority. Its dependable monitoring function helps protect valuable equipment assets and supports long-term operational stability.

By improving visibility into machine conditions, the HY-5V contributes to safer operation, improved production efficiency, and more proactive maintenance strategies for critical rotating machinery.
