Hua Heng HY-3DZ Differential Expansion Monitoring Protection Device | Industrial Safety Monitor

Hua Heng HY-3DZ Differential Expansion Monitoring Protection Device | Industrial Safety Monitor

Brand Name: Hua Heng
Model Number: HY-3DZ
MOQ: 1
Price: Negotiation
Detail Information
Place of Origin:
CHINA
Packaging Details:
New original box
Highlight:

Hua Heng HY-3DZ differential expansion monitor

,

industrial safety monitoring device

,

electronic control relay with warranty

Product Description
Hua Heng HY-3DZ Differential Expansion Monitoring Protection Device
Product Overview

The Hua Heng HY-3DZ Differential Expansion Monitoring Protection Device is an advanced industrial safety monitoring solution designed to support reliable equipment operation and enhance protection in critical industrial environments. This device helps operators identify abnormal equipment behavior and maintain safer, more stable operating processes.

Technical Specifications
Parameter Specification
Measurement Range -3.0 to +5.0mm; -4.00 to +6.00mm; -5.00 to +5.00mm
Input Signal CWY-DO eddy current sensor
Measurement Accuracy Level 0.5, linear error ≤ ±0.5%
Display Mode LED or LCD display
Output Signals Current output: 4-20mA, load resistance ≤ 850Ω
RS485 communication: Modbus RTU protocol
Switching output: DC 27V/2A or AC250V/5A
Operating Environment -40℃ to 65℃, relative humidity ≤ 95% (non-condensing)
Power Supply AC 85V-265V or DC 100V-360V
Installation Method Perforated disc installation
Dimensions Width 160mm * Height 92mm * Depth 210mm
Hole Size Width (152+0.5mm) * Height (76+0.5mm)
Key Features & Benefits
  • Advanced industrial safety monitoring for critical environments
  • Reliable equipment operation and enhanced protection
  • Continuous monitoring to prevent unexpected equipment issues
  • Improved operational efficiency and maintenance strategies
  • Supports condition-based maintenance approaches
  • Industrial durability for demanding working environments
  • Accurate monitoring performance with safety-focused design
Applications

The HY-3DZ is widely suitable for power generation, energy facilities, manufacturing plants, and other heavy industrial environments where machinery performance and safety are key priorities. It supports modern industrial systems by providing critical protection and helping operators make informed decisions.

The Hua Heng HY-3DZ combines dependable monitoring performance with industrial durability to support continuous operation of critical equipment and contribute to more efficient industrial management.
