Fluke PTi120 Pocket Thermal Camera | Compact Infrared Imaging Tool for Quick Visual Troubleshooting

Name: Fluke PTi120 Pocket Thermal Camera | Compact Infrared Imaging Tool for Quick Visual Troubleshooting
Brand: OUTER ELECTRONIC TECHNOLOGY (HK) LIMITED
SKU: PTi120
Price: 210.00 USD
Availability: InStock

Brand Name:	Fluke
Model Number:	PTi120
MOQ:	1
Price:	Negotiation

Detail Information

Product Description

Detail Information

Place of Origin:

OEM

Packaging Details:

New original box

Product Description

Fluke PTi120 Pocket Thermal Camera | Compact Infrared Imaging Tool for Quick Visual Troubleshooting

Portable thermal imagers built for industrial inspection.

Use the right tool for the job, anytime, anywhere.

The bigger the problem, the faster it needs to be solved. The new Fluke pocket-sized thermal imager empowers everyone to minimize downtime. It is your first line of defense for easy troubleshooting. Stop reacting to problems and start preventing them.

Popular because they are practical.

A compact thermal imager you can carry with you every day—hassle-free. Always within reach and ready to use. Resistant to dust and moisture, and built to withstand a 1-meter drop. Now, an enhanced infrared inspection tool fits easily in your pocket, ready to quickly scan the temperatures of electrical equipment, machinery, and other assets.

Automatically save thermal images to the right folder.

Eliminate the tedious task of sorting and organizing infrared images with Fluke Connect Asset Tagging. Simply scan the asset’s QR code or barcode, and all your time-stamped infrared images are stored in a pre-defined folder. Data is transmitted via Wi-Fi or automatically uploaded when you connect to a network or computer via USB. Timely information is key. Now, you can save, locate, and report issues more efficiently—before problems actually occur.

Get the infrared image you expect, every time.

The 3.5-inch LCD touchscreen features IR-Fusion™ technology, blending visible light and infrared images to make locating problems easier. Adjust settings with a simple swipe of your finger.

Key Features

IFOV (spatial resolution) 7.6 mRad

Infrared resolution 120 x 90 (10,800 pixels)

Field of view 50° H x 38° V

Distance-to-spot ratio 130:1

Temperature measurement range (uncalibrated below -10°C) -20 °C to 400 °C

Focus system Fixed focus, minimum focus distance 22.8 cm

USB Micro-USB for image transfer to PC

Wi-Fi Yes

Image Quality

IR-Fusion technology Yes, adds visible details to infrared images

AutoBlend mode Continuous 0% to 100%

Touchscreen 3.5-inch (landscape), 320 x 240 LCD

Rugged, ergonomic design Yes

Thermal sensitivity (NETD) 60 mK

Frame rate 9 Hz

Data Storage and Image Capture

Memory 2 GB internal flash memory

Image capture, review, and save mechanism One-handed image capture, review, and save capability

Image file formats Non-radiometric (JPEG) or fully radiometric (.is2); non-radiometric (JPEG) files do not require analysis software

Software Fluke Connect® desktop software – comprehensive analysis and reporting software with access to the Fluke Connect system

Software export file formats JPG, IS2

Measurement range -20 °C to 400 °C

Battery

Battery (rechargeable) Internal rechargeable lithium-ion battery

Battery life >2 hours continuous use (without Wi-Fi)

Battery charging time ≤ 1.5 hours

Battery charging system Micro-USB cable, connecting the product to a PC

AC operation Using a separate AC-to-USB adapter Not included in the box

Energy saving Auto-off:

5, 10, 15, and 20 minutes or never

Temperature measurement

Temperature measurement range (uncalibrated below -10°C) -20 °C to 400 °C

Accuracy Target temperature 0 °C or above: Accuracy: ± 2 °C or ± 2%

On-screen emissivity correction Yes

On-screen adjustable background temperature compensation Yes

Color palettes

Standard palettes 6: Ironbow, Blue-Red, High Contrast, Amber, Hot Metal, Grayscale

General specifications

Infrared wavelength 8 μm to 14 μm (longwave)

Operating temperature -10°C to +50 °C

Storage temperature -40 °C to +70 °C (-40 °F to 158 °F)

Relative humidity 95% non-condensing

Center point temperature Yes

Spot temperature Hot and cold spot markers

Safety EN 61010-1: Non-CAT, Pollution Degree 2; EN 60825-1: Class 2; EN 60529; EN 62133 (Lithium battery)

Electromagnetic compatibility EN301 489-1 V2.1.1, EN301489-17 V3.1.1

US FCC CFR, Part 15C

Vibration and shock 2G, IEC 68-2-6 and 25G, IEC 68-2-29

Drop 1-meter drop

Dimensions (H x W x L) 8.9 cm x 12.7 cm x 2.5 cm

(3.5 in x 5.0 in x 1.0 in)

Weight (including battery) 0.233 kg (0.514 lb)

Enclosure rating IP54

Warranty Two years

Supported languages Czech, Dutch, English, Finnish, French, German, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, and Turkish
