Honeywell ST 800 series pressure transmitter STD810- E1ACAAS -1-0- DHS -11SA -1 supports SIL 2/3

Name: Honeywell ST 800 series pressure transmitter STD810- E1ACAAS -1-0- DHS -11SA -1 supports SIL 2/3
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: STD810- E1ACAAS -1-0- DHS -11SA -1
Price: 1.00 USD
Availability: InStock

Brand Name:	Honeywell
Model Number:	STD810- E1ACAAS -1-0- DHS -11SA -1
MOQ:	1
Price:	Negotiations

Detail Information

Product Description

Detail Information

Place of Origin:

USA

Power Supply:

Maximum 11 To 42 Volts DC

Allow Working Pressure:

350 KPa Diaphragm

SS Filling Liquid:

DC200

Process Temperature:

-40 To 125 Degrees Celsius

Range:

-2.5 To 2.5 KPa

Packaging Details:

New original box

Highlight:

Honeywell ST 800 pressure transmitter

SIL 2/3 compliant pressure transmitter

STD810 pressure transmitter with warranty

Product Description

Honeywell ST 800 Series Pressure Transmitter STD810-E1ACAAS-1-0-DHS-11SA-1 Supports SIL 2/3

Product Overview

The Honeywell ST 800 series pressure transmitter STD810-E1ACAAS-1-0-DHS-11SA-1 is a high-performance differential pressure transmitter that supports SIL 2/3.

Key Features

Part of the SmartLine® family of products using piezoresistive sensor technology
Combines differential pressure sensing with on-chip static pressure and temperature compensation
High accuracy and stability over wide range of application pressures and temperatures
Accuracy up to 0.035% of span as standard (optional 0.025% of span)
Stability of up to 0.01% of URL per year for 15 years
Automatic static pressure and temperature compensation function
Rangeability up to 400:1
Fast response time (as fast as 90ms)
Multiple local display capabilities
External zero, span, and configuration capabilities
Polarity-insensitive electrical connections
Comprehensive on-board diagnostic capabilities
Integral dual-seal design for highest safety (ANSI/NFPA 70-202 and ANSI/ISA 12.27.0 compliant)
World-class overpressure protection
Fully compliant with SIL 2/3 requirements
Modular design with optional 15-year warranty
Options include plugged impulse line detection and dual/triple calibration (for HART & Fieldbus only)
