JM-B-35 Integrated Bearing Vibration Transmitter,for PLC,DCS or DEH systems

JM-B-35 Integrated Bearing Vibration Transmitter,for PLC,DCS or DEH systems

  • JM-B-35 Integrated Bearing Vibration Transmitter,for PLC,DCS or DEH systems
  • JM-B-35 Integrated Bearing Vibration Transmitter,for PLC,DCS or DEH systems
JM-B-35 Integrated Bearing Vibration Transmitter,for PLC,DCS or DEH systems
Product Details:
Place of Origin: China
Brand Name: OEM
Model Number: JM-B-35
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Packaging Details: Wooden box packing
Delivery Time: 15 days after signing the contract
Payment Terms: T/T
Supply Ability: 1000sets
Contact Now
Detailed Product Description
High Light:

electronic measuring devices

,

rotational speed measurement

Transmitter Series

JM-B-35 Integrated Bearing Vibration Transmitter





Use



    This integrated bearing transmitter mainles apllies to measuring bearing vibration (absolute vibration) in ratating machiney,it has a standard 4~20mA curret output,whitch can be fed to PLC,DCS or DEH systems.It uses two cable system,makes cabling simpie and easy.

Function
1.Mainly applying to measuring bearing vibration (absolute vibration) in ratating machiney.
2.4~20mA analog current (two cable system).
3. Sensor and transmitter are integrated.

Technical parameters
1.Measuring range:10~300Hz
                    Amplitude:0`200чm*﹑ 0~300чm(peak-peak  value)
                    Intensity:0~30mm/s*﹑ 0`30mm/s or 0~40mm/s(RMS value)
2.Measuring accuracy:±0.5 class,linear error≤1%FS
3.Measuring methods:Vertical,horizontal,axial
4.Output signal:Current output:4~20mA(load≤1KΩ)
5.Environmental temperature:-10~65℃(Relative humidity:≤85%)
6.Power votage: DC+24 (power consumed≤3W)
7.External dimension:47×66(mm)
8.Fixed screw hole:M16×1.5×10(depth)
