| Place of Origin: | China |
| Brand Name: | JIANGLING |
| Model Number: | TD-2 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Packaging Details: | Wooden box packing |
| Delivery Time: | 15 days after signing the contract |
| Payment Terms: | T/T |
| Supply Ability: | 1000sets |
| Linearity Impedance: | 250Ω±50Ω (1500Hz) | Excitation: | 1500Hz，10～20VAC |
|---|---|---|---|
| Linear Value: | 25 . 35 . 50mm | Working Temperature: | -10～100℃ |
| Relative Humidity: | ≤90% | ||
| High Light: | 1500Hz Rotary Torque Sensor,Thermal Expansion Rotary Torque Sensor,35mm Default Value Speed Sensor |
||
TD-2 Thermal expansion of the sensor
System description
• for the measurement of thermal expansion
Technical parameters
| Order No. | Description |
| Measurement range | To the order guide |
| Linearity impedance | 250Ω±50Ω (1500Hz) |
| Excitation | 1500Hz,10～20VAC |
| Environment temperature | -10～100℃ (relative humidity ≤90%) |
Order Guide:
| Order No. | Measurement range A |
|
TD-2- Thermal expansion of the sensor |
The default value 35 mm 1:25.0mm 2:35.0mm* 3:50.0mm n:special requirement |
Note : the specific requirement should be provided for special model selection .
Contact Person: Ms. Biona
Tel: 86-755-82861683
Fax: 86-755-83989939
