Quectel SC600Y Series LTE Cat 6 Smart IoT Module | Next-Generation 4G Cellular Connectivity Solution

The SC600Y series represents a next-generation 4G cellular connectivity solution designed for industrial and consumer IoT applications requiring high data rates and advanced multimedia capabilities.

• LTE Cat 6 modem supporting 2 x 20MHz carrier aggregation
• Comprehensive network coverage: LTE, UMTS/HSPA+, and GSM/GPRS/EDGE
• Qualcomm ARM Cortex-A53 64-bit octa-core processor
• Integrated Adreno 506 GPU
• Quick Charge 3.0 technology
• Dual LCD screens and dual touch panels with independent display capabilities
• Main display: 1920 x 1200 @60fps; Secondary display: 1920 x 1080 @60fps
• Supports up to 4 cameras with 2 capable of simultaneous operation
• Multi-constellation GNSS receiver
• 1080p @60fps video recording and playback

The SC600Y series modules measure 43.0mm × 44.0mm × 2.85mm and are available in four regional variants to meet specific market requirements. The series utilizes Multiple-Input Multiple-Output (MIMO) technology to enhance data transmission speeds and reduce errors.

Comprehensive interface options include LCM, camera, touch panel, microphone, UART, USB, and I2C, providing flexibility for diverse IoT applications.

The SC600Y Series enables seamless communication between devices, cloud platforms, and enterprise systems. Its smart architecture supports feature-rich applications requiring both wireless connectivity and local data processing.

Built with strong compatibility in mind, the module simplifies hardware upgrades and reduces development complexity. This flexibility helps shorten development cycles and minimize engineering effort without compromising reliability.

Security features support secure communication between connected devices and cloud services, protecting sensitive business data throughout the product lifecycle.

Industrial automation, smart retail, transportation, healthcare, security, consumer electronics, intelligent terminals, portable devices, digital signage, smart payment systems, telematics, remote monitoring equipment, and various embedded solutions.
