ABB DASD001/3ASC25H241 Analog I/O Extension Board for ACS800 Frequency Converter

The ABB DASD001 (part number 3ASC25H241) is an analog I/O extension board designed as a key option for ABB's high-performance ACS800 series industrial AC drives. This module significantly enhances the drive's interfacing capabilities with external analog signals, providing both additional analog inputs for speed references and analog outputs for process monitoring.

The DASD001 extension board adds extra analog input and output channels to ACS800 drives, enabling flexible integration into complex automation control systems. It allows drives to accept additional analog signals from external PLCs, DCSs, or process instruments (such as pressure or temperature transmitters) to serve as control sources or process parameters. Simultaneously, it outputs internal operating data (including motor current, actual speed, or output power) in analog format to supervisory monitoring systems or recorders.

For applications requiring advanced process control—such as PID regulation or master-follower configurations—installing the DASD001 board is essential for achieving multifunctional integration.

• Enhanced System Integration Flexibility: Expands I/O capabilities to transform ACS800 drives from simple motor speed controllers into feature-rich field control nodes, reducing reliance on central PLCs
• Simplified Wiring and Cost Reduction: Integrates additional AI/AO functions directly into drives, eliminating need for external signal isolators and transmitters
• High Precision and Reliability: Seamlessly integrates with ACS800 drive hardware and firmware, ensuring signal conversion accuracy, stability, and long-term operational reliability
• Powerful Parameter-Based Configuration: Full functionality realized through parameter configuration with flexible definition of signal types, ranges, and output source variables
• Support for Advanced Applications: Additional analog inputs can serve as process feedback signals for built-in PID controller, enabling complete closed-loop control systems

The ABB DASD001/3ASC25H241 is widely used in scenarios requiring drive participation in process control or handling multi-signal interaction:

In central air conditioning systems, drives operate chilled water pumps using expanded AI to receive pipeline pressure signals and built-in PID to regulate pump speed for constant pressure, while transmitting motor current signals to Building Automation Systems (BAS) via AO.

Constant-pressure water supply pumping stations use AI to receive pipeline network pressure data while AO sends frequency signals to SCADA systems. In wastewater treatment plant aeration fan control, AI receives signals from Dissolved Oxygen (DO) sensors to adjust airflow.

In winding/unwinding applications, AI receives signals from tension sensors for constant tension control. In extruders or conveyor lines, used for speed following or proportional linkage.

As part of production lines, receives analog speed setpoints from master PLCs and outputs actual rotational speed or load current as feedback.

The ABB DASD001/3ASC25H241 Analog I/O Extension Board is a professional auxiliary accessory specifically designed for ACS800 series frequency converters, upgrading and expanding industrial control performance of original drive equipment. As a core expansion component, it perfectly matches ACS800 inverter structure and operational logic, solving limitations of native analog signal interfaces and meeting diversified signal transmission and control demands of complex industrial automation systems.

This extension board focuses on stable, precise analog signal input and output expansion, enabling seamless signal interaction between frequency converters and various industrial sensors, controllers, and execution devices. It effectively expands equipment capability to collect on-site operating data and output control signals, making ACS800 frequency converter operation more flexible and adaptable in multi-scenario industrial environments.

Utilizing ABB's mature industrial-grade manufacturing technology, the board features excellent operational stability and strong anti-interference capability, adapting to harsh industrial conditions including variable temperatures, electromagnetic interference, and continuous high-load operation. It supports long-term stable operation without frequent maintenance, significantly improving continuous working reliability of entire frequency conversion control systems.

Easy to install and debug, the board achieves plug-and-play compatibility with ACS800 series converters, requiring no complex program modification or structural adjustment. It is widely applicable to industrial fields including mechanical manufacturing, metallurgy, chemical industry, and water treatment, helping enterprises realize refined frequency conversion control, optimize production operation efficiency, and reduce system operation and maintenance costs.
