Zhong he 8000B Rotating Machinery Vibration Monitoring and Protection System, Industrial Equipment Monitoring Device

Name: Zhong he 8000B Rotating Machinery Vibration Monitoring and Protection System, Industrial Equipment Monitoring Device
Brand: OUTER ELECTRONIC TECHNOLOGY (HK) LIMITED
SKU: 8000B
Price: 210.00 USD
Availability: InStock

Brand Name:	Zhong he
Model Number:	8000B
MOQ:	1
Price:	Negotiation

Detail Information

Product Description

Detail Information

Place of Origin:

China

Packaging Details:

New original box

Highlight:

rotating machinery vibration monitoring system

industrial equipment protection device

digital speed indicator with vibration monitoring

Product Description

Zhonghe 8000B Rotating Machinery Vibration Monitoring and Protection System

Industrial-grade monitoring device for comprehensive rotating machinery protection and predictive maintenance.

Product Overview

The 8000B series is a highly reliable, fully digital, modular, multi-functional monitoring and protection system for rotating machinery. This comprehensive instrument consists of specialized monitoring modules for vibration, speed, overspeed protection, axial displacement, eccentricity, thermal expansion, valve position, and oil tank level monitoring.

Designed for TSI (Turbine Supervisory Instrumentation) system applications, the 8000B series is widely used in power generation, machinery, chemical processing, and metallurgical industries. The system provides multi-parameter measurement and early fault prediction to ensure safe operation of critical rotating equipment.

Key Features

Modular structure allows flexible system configuration with excellent scalability
High intelligence with parameter configuration via handheld computer or PC software
On-site configuration of instrument ranges, alarm values, and operating parameters
Independent microprocessor in each module supports single or dual-channel operation
Combined local and remote monitoring with isolated current output for reliability
Each channel provides 4-20mA analog output and two independent alarm outputs
Automatic recording and query of maximum measured values
Compact handheld computer for convenient field debugging
Comprehensive data acquisition and database management software
MODBUS-RTU communication protocol for easy DCS integration
Multiple communication interfaces: USB, RS485, and RS232
Designed for long-term online monitoring with easy installation and maintenance

Includes modules

Module Code	Description
8000B/000	Chassis
8000B/001	Power Supply
8000B/012	Dual-Channel Bearing Vibration Module
8000B/022	Dual-Channel Shaft Vibration Module
8000B/032	Dual-Channel Axial Displacement Module
8000B/042	Dual-Channel Differential Expansion Module
8000B/051	Single-Channel Speed/Zero Speed/Emergency Shutdown Module
8000B/052	Dual-Channel Speed Module
8000B/061	Single-Channel Eccentricity Module
8000B/072	Dual-channel Thermal Expansion Module
8000B/082	Dual-channel Valve Position Stroke Module
8000B/092	Dual-channel Oil Tank Level Module
8000B/102	Dual-channel Temperature (Thermocouple) Module
8000B/106	Dual-channel Temperature (RTD) Module
8000B/142	Dual-channel Universal Display Module
8000B/150	Keying Phase Module
8000B/162	Three-out-of-two Alarm Module
8000B/053	Single-channel Overspeed Module
