QBJ-3800B Turbine Safety Monitoring Device with 0～4000r/min Speed Range 0～200μm Vibration and 0～±2.0mm Axial Displacement TSI Protection System

Name: QBJ-3800B Turbine Safety Monitoring Device with 0～4000r/min Speed Range 0～200μm Vibration and 0～±2.0mm Axial Displacement TSI Protection System
Brand: OUTER ELECTRONIC TECHNOLOGY (HK) LIMITED
SKU: QBJ-3800B
Price: 1.00 USD
Availability: InStock

Brand Name:	OEM
Model Number:	QBJ-3800B
MOQ:	1
Price:	Negotiations

Detail Information

Product Description

Detail Information

Place of Origin:

China

Rotation Speed:

0～4000r/min

Vibration Amplitude:

0～200μm (PP)

Axial Displacement:

0～±2.0mm

Expansion Difference:

0～±5.0mm

Eccentricity:

0～200μm

Hydraulic Actuator:

0～200mm

Thermal Expansion:

0～35.0mm

Oil Tank Level:

0～±200mm

Key Phase:

0～5VDC

Packaging Details:

New original box

Highlight:

0～4000r/min Turbine Safety Monitoring Device

0～200μm Rotational Speed Sensor

0～±2.0mm TSI Protection System

Product Description

QBJ-3800B Turbine Safety Monitoring Device Shaft Vibration/Displacement/Speed Integrated Protection System

System Overview

The QBJ-3800B turbine safety monitoring and protection system represents the latest generation of TSI protection technology, delivering novel, accurate, safe, and reliable performance. This advanced system is engineered for monitoring and protecting various generator sets and high-speed rotating machinery across industrial applications.

The system integrates original imported high-reliability modules with an intuitive touchscreen interface, providing comprehensive real-time monitoring and protection for up to 24 critical turbine signals including shaft vibration, bearing vibration, axial displacement, differential expansion, eccentricity, and multiple speed protection functions.

Users can freely combine channel content according to their specific requirements. The system supports compatibility with various sensors manufactured by our facility or selected imported sensors, offering the full functionality of premium TSI instruments. For applications requiring more than 24 measuring points, the extended frame model QBJ-3800B/F supports simultaneous monitoring of up to 40 points without compromising functionality.

Key Features

Comprehensive monitoring of up to 24 signals with expandable capacity to 40 points
Touchscreen interface for intuitive operation and real-time monitoring
Flexible channel configuration with user-defined combinations
Compatibility with both domestic and imported sensors
Advanced two-out-of-three overspeed protection logic
Multi-parameter monitoring including vibration, displacement, speed, and thermal parameters

Technical Specifications

System Linearity Accuracy	≤±0.5% (full scale)
Overspeed Protection Response	≤30ms response time
Axial Displacement & Expansion Difference	1 second delay
Vibration Monitoring	Configurable delay settings
Stroke Monitoring	Instant alarm response
Operating Temperature	-10°C to 45°C
Relative Humidity	≤80%
Power Supply	AC 220V ±10% / 50Hz-60Hz
