GE FANUC IC693PWR331 PLC Module 5 Vdc 300 Watts Relay 15 Watts 24 Vdc

Name: GE FANUC IC693PWR331 PLC Module 5 Vdc 300 Watts Relay 15 Watts 24 Vdc
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: IC693PWR331
Price: 210.00 USD
Availability: InStock

Brand Name:	GE
Model Number:	IC693PWR331
MOQ:	1
Price:	Negotiations

Detail Information

Product Description

Detail Information

Place of Origin:

USA

Type:

High-capacity Power Supply

Weight:

1.25 Lbs

Load Capacity:

30 Watts

Series:

90-30 PLC

Rated Voltage:

24VDC / 48VDC

Packaging Details:

New original box

Highlight:

GE FANUC PLC module 5 Vdc 300 Watts

IC693PWR331 relay module 24 Vdc

ESP controller module with 15 Watts

Product Description

GE FANUC IC693PWR331 PLC Module 5 Vdc 300 Watts Relay 15 Watts 24 Vdc

The IC693PWR331 is a GE Fanuc Series 90-30 Programmable Logic Controller (PLC) module. This high-capacity power supply provides three output voltages for various functions.

Technical Specifications

Brand	GE Fanuc
Output Voltage	5 VDC: 300 Watts, maximum 24 VDC Relay: 15 watts maximum 24 VDC Isolated: 20 watts maximum
Inrush Current	4A peak, 100 ms maximum
Input Power	90 VA with VAC Input; 50 W with VDC Input
Input Voltage Range	DC Start: 21 to 56 VDC Run: 18 to 56 VDC
Nominal Rated Voltage	24VDC / 48VDC
No. of Outputs	Three (3)
Protocol Support	RS485
Product Type	High-capacity power supply
Series	90-30 PLC
Part Number	IC693PWR331
Load capacity	30 Watts
Holdup time	14 milliseconds, minimum
LED indicators	PWR, OK, RUN, BATT
Standard	UL, CE
Full load power rating	50 Watts
Number of terminal screws	3
Product Lifecycle Status	Discontinued/Obsolete

Product Features

Provides +5VDC output (30W max), +24VDC Relay output (15W max), and +24VDC isolated output (20W max)
Total output power shall not exceed 30 Watts
RS485 communication terminal for connection to workstations or Hand-Held Programmers
LED indicators (PWR, OK, RUN, BATT) for module status monitoring
Battery back-up maintains contents of PLC's volatile memory
Front panel access to battery connection terminals and wiring termination strip
Input voltage range: 2VDC to 30VDC
Designed for mounting in leftmost slot of Series 90-30 device baseplate

Applications

Powering electronic circuitry on output relay modules
Providing external power for 24VDC input modules
Configuration via GE Proficy Software

Note: This unit should be kept away from dust, dirt, and all heat-generating devices.
