The LTE-A EM06 series 4G LTE module supports high-speed data transmission for multi band applications

Name: The LTE-A EM06 series 4G LTE module supports high-speed data transmission for multi band applications
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: LTE-A EM06
Price: 210.00 USD
Availability: InStock

Brand Name:	Quectel
Model Number:	LTE-A EM06

Detail Information

Product Description

Detail Information

Place of Origin:

China

Highlight:

LTE-A EM06 4G LTE module

4G LTE module multi band

LTE module high-speed data transmission

Product Description

The LTE-A EM06 series 4G LTE module supports high-speed data transmission for multi band applications

Overview

The EM06 is a series of LTE-A Cat 6 IoT modules in an M.2 form factor measuring 42.0mm × 30.0mm × 2.3mm, which meets the 3GPP Release 11 standard. The EM06 delivers maximum downlink rates of 300Mbps and uplink rates of 50Mbps under LTE, and multiple-input multiple-output (MIMO) technology meets demands for data rate and link reliability. The module also supports Qualcomm® IZat™ location technology Gen8C Lite (GPS, GLONASS, BeiDou/Compass, Galileo and QZSS), and the optional multi-constellation GNSS receiver greatly simplifies product design, and provides quicker, more accurate and dependable positioning.

A wide range of internet protocols, industry-standard interfaces and functionalities (such as USB serial drivers for Windows 7/8/8.1/10, Linux, and Android) allow the module to serve a wide range of IoT applications including industrial routers, home gateways, set top boxes, industrial laptops, consumer laptops, industrial PDAs, rugged tablet PCs, video transmission, and digital signage.

Key features

Supports DFOTA
Supports DTMF
Supports MIMO
USB 2.0 high speed interface
Multi-constellation GNSS receiver
