IC698CRE020 for the Rx7i is a high availability 700MHz CPU weighs 1.524 lbs.

Name: IC698CRE020 for the Rx7i is a high availability 700MHz CPU weighs 1.524 lbs.
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: IC698CRE020
Price: 210.00 USD
Availability: InStock

Brand Name:	GE
Model Number:	IC698CRE020
MOQ:	1
Price:	Negotiations

Detail Information

Product Description

Detail Information

Place of Origin:

USA

Packaging Details:

New original box

Highlight:

IC698CRE020 Rx7i CPU

700MHz ESP controller

high availability CPU with warranty

Product Description

IC698CRE020 for the Rx7i

High availability 700MHz CPU weighing 1.524 lbs.

Technical Specifications

Processing Speed	700 MHz
CPU Memory	10 Mbytes
Floating Point	Yes
Serial Ports	3
Serial Protocols	Modbus RTU Slave, SNP, Serial I/O
Embedded Comms	RS-232, RS-486, Ethernet interface

Product Description

The IC698CRE020 is a 700 MHz Central Processing Unit with an Intel Pentium III microprocessor manufactured by GE Fanuc for the RX7i Series. This CPU is equipped with Hot Standby Redundancy to allow critical applications to continue operating in case of failure in any single component.

A Hot Standby system uses two CPUs. One CPU is the active unit that aggressively controls the process, and the other is a backup unit that is synchronized with the active unit and can take over the process when necessary. To accomplish redundancy, the IC698CRE020 requires a Redundancy Memory Xchange module (RMX) catalogued as IC698RMX016. It is normally configured as a redundancy link in each unit.

The IC698CRE020, like any other RX7i CPU, is installed with a software program configured to initiate and complete specific tasks. Such tasks include controlling the device in real time mode, maintaining general machine processes, and handling materials applications.

Additional features of the IC698CRE020 include:

10MBs each of battery-backed memory and non-volatile flash memory
Access to bulk memory
User-configurable data and program memory
Auto-located Symbolic Variables support
90-70 Series discrete and analog I/O support
Series 90-70 VME modules support

To avoid the possibility of losing the CPU's RAM, it is advisable to maintain a routine procedure that involves replacement of the battery pack in due time. The battery is responsible for the overall stability of operations like the calendar clock, data memory, and programs during the absence of power.

Revision Numbers

IC698CRE020A
IC698CRE020B
IC698CRE020C
IC698CRE020D
IC698CRE020E
IC698CRE020F
IC698CRE020G
IC698CRE020H
IC698CRE020I
IC698CRE020J
IC698CRE020K
IC698CRE020L
IC698CRE020M
IC698CRE020N
IC698CRE020P
IC698CRE020Q
IC698CRE020R
IC698CRE020S
IC698CRE020T
IC698CRE020U
IC698CRE020V
IC698CRE020W
IC698CRE020X
IC698CRE020Y
IC698CRE020Z
IC698CRE020-AA
IC698CRE020-AB
IC698CRE020-AC
IC698CRE020-AD
IC698CRE020-AE
IC698CRE020-AF
IC698CRE020-AG
IC698CRE020-AH
IC698CRE020-BA
IC698CRE020-BB
IC698CRE020-BC
IC698CRE020-BD
IC698CRE020-BE
IC698CRE020-BF
IC698CRE020-BG
IC698CRE020-BH
IC698CRE020-CA
IC698CRE020-CB
IC698CRE020-CC
IC698CRE020-CD
IC698CRE020-CE
IC698CRE020-CF
IC698CRE020-CG
IC698CRE020-DA
IC698CRE020-DB
IC698CRE020-DC
IC698CRE020-DD
IC698CRE020-DE
IC698CRE020-DF
IC698CRE020-DG
IC698CRE020-EA
IC698CRE020-EB
IC698CRE020-EC
IC698CRE020-ED
IC698CRE020-EE
IC698CRE020-EF
IC698CRE020-EG
IC698CRE020-FA
IC698CRE020-FB
IC698CRE020-FC
IC698CRE020-FD
IC698CRE020-FE
IC698CRE020-FF
IC698CRE020-FG
IC698CRE020-GA
IC698CRE020-GB
IC698CRE020-GC
IC698CRE020-GD
IC698CRE020-GE
IC698CRE020-GF
IC698CRE020-GG
IC698CRE020-GJ
IC698CRE020-GK
IC698CRE020-HA
IC698CRE020-HB
IC698CRE020-HC
IC698CRE020-JC
IC698CRE020-JD
IC698CRE020-JE
