ABB's Modulebus Digital I O Module Redundant Single I/O, Single Power TU841 3BSE020848R11

Name: ABB's Modulebus Digital I O Module Redundant Single I/O, Single Power TU841 3BSE020848R11
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: TU841 3BSE020848R11
Price: 210.00 USD
Availability: InStock

Brand Name:	ABB
Model Number:	TU841 3BSE020848R11
MOQ:	1
Price:	Negotiations

Detail Information

Product Description

Detail Information

Place of Origin:

India

Packaging Details:

New original box

Highlight:

ABB Modulebus digital I/O module

redundant single I/O module

TU841 3BSE020848R11 Modulebus module

Product Description

ABB's Modulebus Digital I/O Module Redundant Single I/O, Single Power TU841 3BSE020848R11

Features and Benefits

A rotary switch for cluster address setting
Mechanical keying prevents insertion of wrong module type
Single ModuleBus connection
Latching device to DIN rail for locking and grounding
DIN rail mounted

The TU841 is a module termination unit (MTU) for redundant configuration of Optical ModuleBus Modem TB840/TB840A, for use with non-redundant I/O.

The MTU is a passive unit having connections for power supply, a single electrical ModuleBus, two TB840/TB840A and a rotary switch for cluster address (1 to 7) setting.

Four mechanical keys, two for each position, are used to configured the MTU for the right types of modules. Each key has six positions, which gives a total number of 36 different configurations. The configurations can be changed with a screwdriver.

Termination Unit TU840 connects TB840/TB840A to redundant I/O. Termination Unit TU841 connects TB840/TB840A to non-redundant I/O.

General Information

Protocol	ABB's Modulebus
Article number	3BSE020848R11
Master or slave	Not Applicable
Line redundancy	Yes
Hot Swap	No
Type	Redundant TB840/TB840A, Single I/O, Single Power
Power input	24 V d.c (19.2 - 30 V)
Mounting	Vertical or Horizontal

Detailed Data

24 V consumption typ.	N/A
ModuleBus current distribution	Maximum 5 V 1.5 A 24 V 1.5 A
Mechanical Keys	36 different combinations
Acceptable wire sizes	Solid: 0.2 - 2.5 mm² Stranded: 0.2 -2.5 mm², 24 -12 AWG Recommended torque: 0.5 Nm
Rated insulation voltage	50 V
Dialectic test voltage	500 V a.c
Power dissipation	2.0 W

Environmental and Certification

Temperature, Operating	55° C (131° F) horizontal mounted. 40° C (104° F) vertical mounted
Temperature, Storage	-25° C (-13° F) to +70° C (158° F)
Equipment class	Class 1 according to IEC 60536; (earth protected)
Ingress protection	IP20 according to IEC 60529
CE-marking	Yes
Electrical Safety	cULus
Hazardous location	cULus Hazardous Location Class 1 Zone 2, ATEX Zone 2
Marine certificates	ABS, BV, DNV-GL, LR, RS, CCS
RoHS compliance	EN 50581:2012
WEEE compliance	DIRECTIVE/2012/19/EU

Dimensions

Height	186 mm (7.32 in.) including latch
Width	124 mm (4.88 in.)
Depth	47 mm (1.85 in.)
Weight (including base)	0.45 kg (0.99 lbs.)
