Schneider 140DVO85300 output 32 points 10-30 VDC 4 sets of isolation 0.5A point

Name: Schneider 140DVO85300 output 32 points 10-30 VDC 4 sets of isolation 0.5A point
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: 140DVO85300
Price: 210.00 USD
Availability: InStock

Brand Name:	Schneider
Model Number:	140DVO85300
MOQ:	1
Price:	Negotiations

Detail Information

Product Description

Detail Information

Place of Origin:

France

Packaging Details:

New original box

Highlight:

Schneider 32-point output module

10-30 VDC isolation module

0.5A low voltage protection device

Product Description

Schneider 140DVO85300 Output Module

32 Points 10-30 VDC, 4 Sets of Isolation, 0.5A Point

Product Overview

Main Range of Product:

Modicon Quantum automation platform

Product Type:

DC Discrete Output Module

Technical Specifications

Discrete Output Number	32
Channel Groups	4 groups of 8
Output Logic	Negative logic (sink)
Addressing Requirement	2 output words, 2 input words
Output Voltage	10...30 V DC
Maximum Voltage Drop	<0.4 V @ 0.5 A
Maximum Load Current	<= 0.5 A each point, <= 16 A per module, <= 4 A each group
Response Time	<= 2 ms state transitions
Protection	Short-circuit and output overvoltage protection

Additional Specifications

Power Dissipation: 2.5 W + (0.1 x all points on) + (0.4 x total load current)
Net Weight: 0.66 lb (0.3 kg)
Operating Temperature: 32...140 °F (0...60 °C)
Storage Temperature: -40...185 °F (-40...85 °C)
Relative Humidity: 95% without condensation
Operating Altitude: <= 16,404 ft (5,000 m)

Certifications & Compliance

Standards: UL 508, CSA C22.2 No 142
Certifications: GOST, FM Class 1 Division 2, RMRS, C-Tick
Marking: CE

Environmental Information

California Proposition 65: WARNING: This product can expose you to chemicals including Lead and lead compounds which is known to the State of California to cause Carcinogen & Reproductive harm.

REACh Regulation: Declaration
EU RoHS Directive: Declaration
China RoHS Regulation: Declaration
Environmental Disclosure: Product Environmental Profile
