Low Voltage TSX Modicon Quantum PLC 24V DC Input Module140DDI35300

Schneider Modicon TSX Modicon Quantum 140DDI35300 24V DC Input Module

• SCHNEIDER ELECTRIC
• MODICON
• 140-DDI-353-00
• 140DDI35300
• DISCRETE DC INPUT MODULE 24V 4 X 8 SINK
• AVAILABLE
• New one with one year warranty and used one with six months warranty
• Weight: 0.70 lbs

• SCHNEIDER ELECTRIC 043-502-736
• SCHNEIDER ELECTRIC 043-509-298
• SCHNEIDER ELECTRIC 140DDI35300
• SCHNEIDER ELECTRIC 79382

Discrete Input Module Modicon Quantum - 32 I 24 V DC

Quantum | 140DDI35300 | Modicon | 140 DDI 353 00 | DC INPUT 24VDC 4X8 SINK

The Quantum 140DDI35300 Discrete DC Input Module accepts (32) 24VDC inputs. The module is a 4x8 (4 groups, 8 inputs each) Sink input card and is for use with source output devices. A Quantum removable terminal strip allows for easy maintenance. Quantum backplanes (ordered separately) come in 2,3,4,6,10, and 16 slot versions. Any Quantum module can be used in any slot. A Quantum power supply is required in each rack. The power supply provides logic power to all modules on the bus. All Quantum I/O modules are optically isolated from the bus, ensuring safe and trouble-free operation.

• CSA C22.2 No 142
• UL 508

• Resistance to electrostatic discharge: 4 kV contact conforming to IEC 801-2, 8 kV on air conforming to IEC 801-2
• Resistance to electromagnetic fields: 9.14 V/yd (10 V/m) 80...2000 MHz conforming to IEC 801-3
• Ambient air temperature for operation: 32...140 °F (0...60 °C)
• Ambient air temperature for storage: -40...185 °F (-40...85 °C)
• Relative humidity: 95% without condensation
• Operating altitude: ≤ 16404.2 ft (5000 m)

The Modicon Quantum Ethernet I/O (QEIO) automation platform is designed to meet the requirements of both the industrial automation and process industries. An integral part of the PlantStruxure™ architecture, Modicon Quantum Ethernet I/O supports remote I/O architectures that meet your physical requirements today, as well as being both scalable and flexible - to adapt to future modifications of your installation.
