Schneider Electric 140NOM25200 MB network adapter fiber optic interface 1 CH New Original

Name: Schneider Electric 140NOM25200 MB network adapter fiber optic interface 1 CH New Original
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: 140NOM25200
Price: 210.00 USD
Availability: InStock

Brand Name:	Schneider
Model Number:	140NOM25200
MOQ:	1
Price:	Negotiations

Detail Information

Product Description

Detail Information

Place of Origin:

France

Packaging Details:

New original box

Highlight:

Schneider Electric fiber optic network adapter

MB network adapter 1 CH

Low voltage protection fiber optic interface

Product Description

Schneider Electric 140NOM25200 MB Network Adapter Fiber Optic Interface 1 CH New Original

Product Overview

Main range of product: Modicon Quantum automation platform

Product or component type: DIO head-end adaptor

Technical Specifications

Complementary number of port: 1 Modbus Plus fiber optic single copper, 1 Modbus RS232 twisted pair

Transmission rate: 1 Mbit/s

Electrical connection: 1 connector RJ45, 2 connectors TX/RX

I/O words: 30 I/32 O

Checks: RAM, RAM address, Processor, Checksum

Power dissipation: 4 W

Minimum pulse width distortion/jitter: 5 ns

Wavelength: 820 nm

Power loss budget: 11 dB 62.5/125 µm, 16.5 dB 100/140 µm, 6.5 dB 50/125 µm

Optical transmission: -16...-9 dBm 100/140 µm, -19.8...-12.8 dBm 50/125 µm, -3.5...110.5 dBm 62.5/125 µm

Rise/fall time: 20 ns

Dynamic range: 20 dB

Detected silence: -36 dBm

Sensitivity scale: > 30 dBm

Bus current requirement: 750 mA

Environmental Specifications

Resistance to electrostatic discharge: 4 kV contact conforming to IEC 801-2, 8 kV on air conforming to IEC 801-2

Resistance to electromagnetic fields: 10 V/m 80...2000 MHz conforming to IEC 801-3

Ambient air temperature for operation: 0...60 °C

Ambient air temperature for storage: -40...85 °C

Relative humidity: 95% without condensation

Operating altitude: ≤ 5000 m

Certifications & Standards

Standards: UL 508

Product certifications: CSA Class 1 Division 2, RINA, GL, RMRS, C-Tick, GOST, DNV

Sustainability Information

Sustainable offer status: Green Premium product

REACh Regulation: REACh Declaration

EU RoHS Directive: Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration

Mercury free: Yes

RoHS exemption information: Yes

China RoHS Regulation: China RoHS declaration

Environmental Disclosure: Product Environmental Profile

Circularity Profile: End of Life Information

WEEE: The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Similar Model Products

140ACI03000

140DDI15310

140DAI55300

140DAO84210

140ACI04000

140DDI35300

140DAI74000

140DAO84220

140ACO02000

140DDI35310

140DAI75300

140DAO85300

140AII33000

140DDI36400

140DSI35300

140DRA84000

140AII33010

140DDI84100

140DDO15310

140DRC83000

140AIO33000

140DDI85300

140DDO35300

140DVO85300

140AMM09000

140DAI34000

140DDO35301

140DDM39000

140ARI03010

140DAI35300

140DDO35310

140DDM69000

140ATI03000

140DAI45300

140DDO36400

140DAM59000

140AVI03000

140DAI54000

140DDO84300

140DII33000

140AVO02000

140DAI54300

140DDO88500

140DIO33000

140DAO84000

140DAO84010

(1) CPUs updated with the Unity Pro firmware.

(2) The addition of a complete Ethernet RIO drop function is available for these CPUs with Unity Pro u V7.0.

Product Image
