Schneider 140ESI06210 ASCII serial communication module RS232 2 channels new original

Name: Schneider 140ESI06210 ASCII serial communication module RS232 2 channels new original
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: 140ESI06210
Price: 210.00 USD
Availability: InStock

Brand Name:	Schneider
Model Number:	140ESI06210
MOQ:	1
Price:	Negotiations

Detail Information

Product Description

Detail Information

Place of Origin:

France

Packaging Details:

New original box

Highlight:

Schneider ASCII serial communication module

RS232 serial module 2 channels

Schneider 140ESI06210 communication module

Product Description

Schneider 140ESI06210 ASCII Serial Communication Module RS232 2 Channels

Product Overview

New original ASCII serial communication module with 2 RS232 channels for the Modicon Quantum automation platform.

Technical Specifications

Product Range	Modicon Quantum automation platform
Component Type	ASCII serial link module
Compatible Software	Concept > V2 ProWORX 32 > V2 ProWORX NxT > V2 Unity Pro > V2
CPU Compatibility	All Quantum CPU
Application	For standard applications
Transmission Mode	ASCII
Ports	2 RS232C non-isolated (conforming to DIN 66020)
Electrical Connection	2 SUB-D 9 connectors
Transmission Rate	19.2 kbit/s
Maximum Cable Distance	<20 m
Message Nesting	8 levels
Buffer Size	255 I bytes / 255 O bytes
Number of Messages	255
Message Length	127 characters + 1 checksum maximum
Clock	With calendar clock
Memory Capacity	128 kB flash / 32 kB RAM
Power Dissipation	2 W
Addressing Requirement	12 output words / 12 input words
Bus Current Requirement	300 mA
Module Format	Standard
Weight	0.3 kg

Environmental Specifications

EMF Resistance	10 V/m 80...1000 MHz (conforming to IEC 801-3)
Operating Temperature	0...60 °C
Storage Temperature	-40...85 °C
Relative Humidity	95% without condensation
Operating Altitude	<= 5000 m

Sustainability Information

Status	Green Premium product
REACh Regulation	REACh Declaration
EU RoHS Directive	Pro-active compliance (Product out of EU RoHS legal scope) EU RoHS Declaration
Mercury Free	Yes
RoHS Exemption	Yes
China RoHS	China RoHS declaration
Environmental Disclosure	Product Environmental Profile
Circularity Profile	End of Life Information
WEEE Compliance	The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
