56-03-22-38-HT EMERSON Analyzer Dual Input Control 265VAC 50/60HZ 20 Watt

Featuring USB capabilities, a high-quality screen, and HART communication signal, the Rosemount 56 Transmitter provides accurate and reliable readings for pH or ORP measurements. The high resolution, full-color screen provides easy-to-read measurements and data trend graphs and provides customizable display options for the user.

• USB data port for downloading process data and alarm conditions
• Ability to upload and download analyzer configurations
• 85-264 VAC switching power, 50/60 Hz with four alarm relays
• HART digital communication signal for increased visibility of process parameters
• Measurement ranges: 0 to 14 for pH and -1500 to +1500mV for ORP
• Ideal for water/wastewater, pulp and paper, oil and gas, chemical, refining, food and beverage, life sciences, and power industries

The 56 Advanced Dual-Input Analyzer enables continuous measurement of liquid analytical data from either one or two sensors. Its modular design allows for on-site replacement of signal input boards, facilitating easy configuration adjustments. The high-resolution full-color display delivers exceptional visibility and functionality.

The 56 Analyzer supports single or dual sensor inputs, with unlimited options for combining dual measurements. Measurement capabilities include:

• pH/ORP
• Resistivity/conductivity
• Concentration percentage
• Total chlorine, free chlorine, monochloramine
• Dissolved oxygen, dissolved ozone
• Turbidity, pulse flow, temperature
• 4-20mA input

• Two isolated inputs
• Nine local languages
• Four 4-20mA current outputs
• Detachable connectors for power and current outputs
• Four solid plugs for sealing openings
• HART digital communication included
• Profibus digital communication available as an option
