Industrial Grade 5.7" VGA Human Machine Interface Touch Screen Mitsubishi Electric GT2705-VTBD

Manufacturer : Mitsubishi Electric

GT2705-VTBD

GT 2705 - VTBD

Overview : 5.7 type VGA [640 × 480]

TFT color liquid crystal 65536 color

memory 32 MB DC type

panel color: black

multi touch supported

Category : GOT body

series : GOT 2000

Classification : Medium size: 4.7 ~ 7 type

Product model name : GT 2705 - VTBD

Model name : GT 27

Conforming standard : UL / cUL, CE (EMC), CE (RoHS), KC, ABS, BV, DNV GL, LR, NK, RINA

Display unit: -

type : TFT color liquid crystal

Screen size : 5.7 type

resolution : VGA: 640 × 480 [dot]

Display size : 115.2 (W) x 86.4 (H) [mm]

Number of display characters : In 16-dot standard font: 40 characters × 30 lines (full-width) 12 dot In standard font: 53 characters × 40 lines (full-width)

Display color : 65536 colors

Brightness adjustment : 32 step adjustment

Maximum number of images that can be registered : 4096 screen

Backlight: -

type : LED (can not be replaced)

lifespan : Approximately 60,000 hours (time at which the display luminance becomes 50% at an ambient temperature of 25 ° C.)

color : White

Touch panel: -

method : Analog resistor type

Key size : Minimum 2 × 2 [dots] (per one key)

Number of simultaneous press points : Up to 2 points

lifespan : 1 million times or more (operation force 0.98 N or less)

Human sensor: -

Detection distance : -

Detected temperature : -

User memory: -

Memory capacity : Storage memory (ROM): 32 MB Operating memory (RAM): 80 MB

Lifetime (number of writes) : 100 thousand times

Internal clock accuracy : ± 90 seconds / month (ambient temperature 25 ° C)

Battery: -

type : GT 11 - 50 BAT type lithium battery

Backup target : SRAM data, clock data, system status log data

lifespan : About 5 years (ambient temperature 25 ?)

Internal interface: -

bus : -

RS-422/485 (shared) : 1 ch Transmission speed: 115200/57600/38400/19200/9600/4800 bps Connector shape: D sub 9 pins (female)

RS-422/232 (shared) : -

RS-422 : -

RS-232 : 1 ch Transmission speed: 115200/57600/38400/19200/9600/4800 bps Connector shape: D sub 9 pins (male)

Ethernet : 1 ch data transfer method: 100 BASE - TX / 10 BASE - T connector shape: RJ - 45 (modular jack)

RGB : -

Printer : -

USB (device) : Maximum transfer rate: High-Speed ??480 Mbps 1 ch (Front) Connector shape: USB Mini-B

USB (host) : Maximum transfer speed: High-Speed ??480 Mbps 2 ch (front / rear) Connector shape: USB-A

SD memory card : 1ch SDHC compatible (up to 32GB)

CF card : -

PC card slot : -

Option function board : -

Memory board : -

Extended interface : 1ch for mounting communication unit / option unit

Extended auxiliary interface : -

Side interface : 1ch for mounting communication unit

Wireless LAN communication unit interface : -

Audio output interface : -

Switch 1 : -

Switch 2 : -

Buzzer output : Single tone (pitch and tone length adjustable)

POWER LED : Luminescent color: 2 colors (blue, orange)

Protective structure : Front portion: IP 67 F Panel inside: IP 2 X

External dimensions : 167 (W) x 139 H) x 60 (D) [mm]

Panel cut dimensions : 153 (W) 121 (H) [mm]

Mass (excluding mounting hardware) : 1.0 [kg]

Operating ambient temperature : 0 to 55 ° C

Storage ambient temperature : -20 ° C to 60 ° C

Ambient operating humidity : 10 to 90% RH, non condensing

Storage ambient humidity : 10 to 90% RH, non condensing

Anti-vibration : Compliance standard : Meets JIS B 3502, IEC 61131-2

Anti-vibration When there is intermittent vibration : <Frequency: 5 to 8.4 Hz> Partial amplitude 3.5 mm, Number of sweeps X, Y, Z 10 times in each direction <Frequency: 8.4 to 150 Hz> Acceleration 9.8 m / s 2 , Number of sweeps X, Y,

Anti-vibration When there is continuous vibration : <Frequency: 5 to 8.4 Hz> Single amplitude 1.75 mm <Frequency: 8.4 to 150 Hz> Acceleration 4.9 m / s 2

Impact resistance : Meets JIS B 3502, IEC 61131-2 (147 m / s 2 (15 G) 3 times in X, Y, Z direction each)

Use atmosphere : There is no oil smoke, corrosive gas, flammable gas, conductive dust is not serious, it is not exposed to direct sunlight (also during storage)

Use elevation : 2000 m or less

Installation location : In the control panel

Over Voltage category : II or less

Pollution degree : 2 or less

cooling method : Self-cooling

Input supply voltage : DC 24 V (+ 25%, - 20%)

Input frequency : -

Input maximum apparent power : -

power consumption: -

At maximum load : 30 W or less

Main unit body : 7W

Main unit (when backlight is off) : 5 W

Inrush current : 69 A or less (1 ms, ambient temperature 25 ° C., maximum load)

Allowable momentary power failure time : Within 10 ms

Noise tolerance : Noise voltage with 500 Vp-p, noise width 1 µs, noise frequency of 25 to 60 Hz by noise si

tor

Withstand voltage : Power supply terminal all together ? earth ground AC 350V 1 minute

Insulation resistance : Power supply terminal all together ? ground DC 500 V at insulation resistance meter 10 MO or more

Applicable wire size : 0.75 to 2 [mm 2 ]

Applicable crimp terminal : Crimp terminals for M3 screw RAV1.25-3, V2 - S3.3, V2 - N3A, FV2 - N3A

Applicable tightening torque (terminal block terminal screw) : 0.5 to 0.8 [N · m]

ground : Class D grounding (type 3 grounding), connecting to the board when grounding is impossible

Mounting type : standard

Shipping Weight : 2 Kg
