Power supply 24VDC Mitsubishi GT2708-STBD Human Machine Interface Touch Screen

Name: Power supply 24VDC Mitsubishi GT2708-STBD Human Machine Interface Touch Screen
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: GT2708-STBD
Price: 210.00 USD
Availability: InStock

Brand Name:	Mitsubishi
Model Number:	GT2708-STBD
MOQ:	1
Price:	Negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	In Stock

Detail Information

Product Description

Detail Information

Place of Origin:

Japan

Certification:

Packaging Details:

New Original Box

Supply Ability:

In Stock

Highlight:

24VDC Human Machine Interface Touch Screen

Human Machine Interface Touch Screen

Product Description

Detailed Product Description

Brand:	Mitsubishi	Model Item:	GT2708-STBD
Plan Of Original:	Japan	Screen Size:	8.4"
Manufacturer Series:	GOT 2000	Resolution:	800 X 600pixels
Supply Voltage:	100-240VAC	Power Supply:	24 V Dc
Stand Alone:	15W
Highlight:	hmi display touch screen , industrial hmi panels

Power supply 24VDC Mitsubishi GT2708-STBD Human Machine Interface Touch Screen

Product Details

GT27 8.4 INCH SVGA COLOR TOUCHSCREEN DC (GT2708STBD)
Manufacturer: Mitsubishi
Series: GOT2000

GOT2000 HMI SVGA

Mitsubishi Electric GOT2000 HMIs provide the user with a comprehensive range of options to ensure your application or process is covered. Comes equipped with a high speed CPU for responsive HMI operation even under high load processes including logging and device data transmission. Supporting a wide variety of communication options including RS232, RS485/422 and Ethernet making this series of HMI very versatile

Premium processor coupled with expanded memory
Multi-touch operation
Wide variety of communication functions to ensure your application is covered
Double the speed for monitoring & booting of previous generation
Simplified setup and debugging controls for simple setup
Supports a wide variety of image formats, including PNG
Available in a variety of screen sizes, ranging from 7" - 15"

Quick Detail


Condition	New
Weight (kg)	1.5
Our Part Number	GT2708STBD
Height (mm)	194
Width (mm)	241
Depth (mm)	52
Manufacturer	Mitsubishi
Manufacturer Range	GOT
Manufacturer Series	GOT 2000
IP Rating	IP67
IP Rating Back	IP20
Display Colour	65536
Display Resolution	800 x 600
Display Size	8.4"
Display Type	TFT
Backlighting	Yes
Internal Memory (Mb)	128
Keyboard Type	Touch Screen

Specifications

Attribute	Value
Manufacturer Series	GT27
Product Range	GOT2000
Display Type	TFT LCD
Display Size	8.4 in
Display Resolution	800 x 600pixels
Display Colour	Colour
Number of Ports	10
Port Type	Auxiliary Extension I/F, Ethernet, Extension Interface, RS232, RS422/485, SD Card, Side Interface, USB, 2 x USB Host
Processor Type	Programmable Controller CPU
Processor Speed	0.00015MHz
Onboard Memory	57 (Storage) MB, 128 (Operation) MB
Backlighting	Yes
Supply Voltage	24 V dc
Width	241mm
Depth	52mm
Minimum Operating Temperature	0°C
Length	194mm
IP Rating	IP2X, IP67F
Dimensions	194 x 241 x 52 mm
Maximum Operating Temperature	+55°C

High Specification Models With Multi-Touch/Gesture Control

The operating terminals of the GT27 series provide TFT LCD displays with 65K colours and screen sizes of 5.7", 8.4", 10.4", 12.1" and 15" with VGA/SVGA/XGA resolution and up to 128MB internal memory. All terminals come with Ethernet, USB, RS232, and RS422/485 interfaces and SD card slot. Additionally the GT27 can be equipped with optional interfaces like CC-Link IE, CC-Link IE Field, CC-Link, MELSECNET/H and a direct connection to the PLC bus.

Special models of the GT27 with the sizes of 10.4" and 12.1" are available with a white frame and without the front USB interface, ideal for Food and Beverage applications.

The GT27 offers several pre defined diagnostic and troubleshooting functions, like backup/restore, PLC program monitor, servo/motion monitor, motion SFC monitor and CNC monitor.
