Human Machine Interface Touch Screen size 10.4 inch GT2510-VTWD Mitsubishi Electric

Name: Human Machine Interface Touch Screen size 10.4 inch GT2510-VTWD Mitsubishi Electric
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: GT2510-VTWD
Price: 285.00 USD
Availability: InStock

Brand Name:	Mitsubishi
Model Number:	GT2510-VTWD
MOQ:	1
Price:	Negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	In Stock

Detail Information

Product Description

Detail Information

Place of Origin:

Japan

Certification:

Packaging Details:

New Original Box

Supply Ability:

In Stock

Product Description

Detailed Product Description

Brand:	Mitsubishi	Model Item:	GT2510-VTWD
Plan Of Original:	Japan	Screen Size:	10.4"
Internal Memory:	38MB	Resolution:	800 X 600pixels
Supply Voltage:	100-240VAC	Power Supply:	24 V Dc
Keyboard::	Touch Screen
Highlight:	hmi display touch screen , industrial hmi panels

Human Machine Interface Touch Screen size 10.4 inch GT2510-VTWD Mitsubishi Electric

Detailed Product Description

◆ Display device: TFT color LCD screen

◆ Screen size: 10.4 inches

◆ GT2510-VTWD resolution: VGA: 640*480 points

◆ Display size: 211.2 (8.315) (W) * 158.4 (6.236) (H) mm (inch)

◆ Display the number of characters:

·16 dot matrix standard font: 40 words * 30 lines (full angle)

·12 dot matrix standard font: 53 words * 40 lines (full angle)

◆ Display color: 65536 colors

◆ Brightness adjustment: 32 levels

◆ Maximum number of screens that can be registered: 4096 screens

◆ Background light: LED (cannot be replaced)

◆ Background lamp life: about 60,000 hours (using the ambient temperature of 25 ° C, the time when the brightness is 50%)

【touch screen】

◆ Mode: Analog resistance film method

◆ Key size: minimum 2*2 points (per key)

◆ Press the number of points at the same time: Can not press simultaneously

◆ Life: more than 1 million times (operating force of 0.98N or less)

Product Details

GT25 10.4 INCH WHITE VGA COLOR TOUCHSCREEN DC (GT2510VTWD)
Manufacturer: Mitsubishi
Series: GOT2000

Specifications

Screen size:	10.4"
Display type:	TFT, LCD colour
Display dimensions:	w211.2 x h158.4mm
Graphical resolution:	640 x 480 pixels
Power supply:	24V d.c.
Interface:	RS422/485, RS232, Ethernet (TCP/IP), USB (rear) and SD card
Overall dimensions:	w303 x h218 x d52mm

Features:

Built-in Ethernet, RS232 & RS422/485
SD memory card slot
Operator authentication and logging
Wide choice of drivers for Mitsubishi and other manufacturers controllers
All versions have 65K colour screens
Oil resistant protective sheets available

Quick Detail

Condition	New
Weight (kg)	2.1
Our Part Number	GT2510VTWD
Height (mm)	218
Width (mm)	303
Depth (mm)	52
Manufacturer	Mitsubishi
Manufacturer Range	GOT
Manufacturer Series	GOT 2000
IP Rating	IP67
IP Rating Back	IP20
Display Colour	65536
Display Resolution	640 x 480
Display Size	10.4"
Display Type	TFT
Backlighting	Yes
Internal Memory (Mb)	80
Keyboard Type	Touch Screen

GT25 model

Model		Screen size	Display section Display color	Panel color	Power	Remarks
GT2512	GT2512-STBA	12.1" SVGA	TFT color 65536 colors	Black	100 to 240 V AC	-
	GT2512-STBD			Black	24 V DC	-
	GT2512F-STNA			-	100 to 240 V AC	Open frame model
	GT2512F-STND			-	24 V DC	Open frame model
GT2510	GT2510-VTBA	10.4" VGA		Black	100 to 240 V AC	-
	GT2510-VTBD			Black	24 V DC
	GT2510-VTWA			White	100 to 240 V AC
	GT2510-VTWD			White	24 V DC
	GT2510F-VTNA			-	100 to 240 V AC	Open frame model
	GT2510F-VTND			-	24 V DC	Open frame model
GT2508	GT2508-VTBA	8.4" VGA		Black	100 to 240 V AC	-
	GT2508-VTBD			Black	24 V DC
	GT2508-VTWA			White	100 to 240 V AC
	GT2508-VTWD			White	24 V DC
	GT2508F-VTNA			-	100 to 240 V AC	Open frame model
	GT2508F-VTND			-	24 V DC	Open frame model
GT2505	GT2505-VTBD	5.7" VGA		Black	24 V DC	-
