Schneider Electric Programable Logic Controller 140CPS11420 Power Supply Module

Programmable Logic Controller SCHNEIDER ELECTRIC 140CPS11420 POWER SUPPLY MODULE

Main
Range of product Modicon Quantum automation platform
Product or component type Power supply module
Power supply type Summable or standalone

Complementary

Input voltage 230 V AC 170...276 V
115 V AC 93...132 V 47...63 Hz
Input current 750 mA 230 V
1300 mA 115 V
Inrush current 38 A 115 V
19 A 230 V
Rated power in VA 130 VA
Associated fuse rating 2 A slow-blow
Harmonic distortion <= 10 % of fundamental rms value
Output voltage 5.1 V DC
Power supply output current 20 A 60 °C summable
11 A 60 °C standalone
Output overvoltage protection Internal
Output overload protection Internal
Power dissipation 6 + (1.5 x Iout) where Iout is in A
Alarm output 1 NC 6 A 220 V power supply fault
Local signalling 1 LED green power (PWR OK)
Marking CE
Module format Standard
Product weight 0.65 kg

Environment
Standards CSA C22.2 No 142 UL 508
Product certifications CUL
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2
4 kV contact conforming to IEC 801-2
Resistance to electromagnetic fields 10 V/m 80...2000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0...60 °C
Ambient air temperature for storage -40...85 °C
Relative humidity 95 % without condensation
Operating altitude <= 5000 m

Offer Sustainability
Sustainable offer status Green Premium product
RoHS Compliant - since 0851 - Schneider Electric declaration of conformity
REACh Reference contains SVHC above the threshold - go to CaP for more details
Product environmental profile Available Download Product Environmental
Product end of life instructions Need no specific recycling operations

Contractual warranty Period 18 months
