Rosemount 3051TG In Line Pressure Transmitter 3051TG3A2B21AB4 14.7 to 800PSI

Name: Rosemount 3051TG In Line Pressure Transmitter 3051TG3A2B21AB4 14.7 to 800PSI
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: 3051TG3A2B21AB4
Price: 210.00 USD
Availability: InStock

Brand Name:	Rosemount
Model Number:	3051TG3A2B21AB4
MOQ:	1
Price:	Negotiations

Detail Information

Product Description

Detail Information

Place of Origin:

OEM

Warranty:

One Year

MOQ:

1 Piece

Range:

-14.7 To 800 Psi

Type:

Pressure Transmitter

Communication Protocol:

4-20 MA HART

Packaging Details:

New original box

Highlight:

In Line Pressure Transmitter

800PSI Pressure Transmitter

3051TG In Line Pressure Transmitter

Product Description

Description of Rosemount 3051TG In Line Pressure Transmitter 3051TG3A2B21AB4 14.7 to 800PSI

With the Rosemount 3051 Pressure Transmitter, you’ll gain more control over your plant. You’ll be able to

reduce product variation and complexity as well as your total cost of ownership by leveraging one device

across a number of pressure, level and flow applications. You’ll have access to information you can use to

diagnose, correct and even prevent issues. And with unparalleled reliability and experience, the Rosemount

3051 is the industry standard that will help you perform at higher levels of efficiency and safety so you can

remain globally competitive.

Quick Details:

Rosemount 3051T In-Line Pressure Transmitters are the industry standard for Gage and

Absolute pressure measurement. The in-line, compact design allows the transmitter to

be connected directly to a process for quick, easy and cost effective installation.

Capabilities include:

 Power Advisory can proactively detect degraded electrical loop integrity issues

(Option Code DA0)

 Local Operator Interface with straightforward menus and built-in configuration

buttons (Option Code M4)

 Safety Certification (Option Code QT)

Specifications:

Rangedown	Up to 150:1
Communication Protocol	4-20 mA HART, WirelessHART®, FOUNDATION fieldbus, Profibus, 1-5 V Low Power HART
Measurement Range	Up to 2000psi (137,89 bar) Differential, Up to 2000psig (137,89 bar) Gage, Up to 4000psia (275,79 bar) Absolute
Process Wetted Material	316L SST, Alloy C-276, Alloy 400, Tantalum, Gold-plated Alloy 400, Gold-plated 316L SST
Diagnostics	Basic Diagnostics, Power Advisory Diagnostics
Certifications/Approval	SIL 2/3 certified to IEC 61508 by an independent 3rd party, NSF, NACE, hazardous location, see full specs for complete list of certifications
