ALLEN BRADLEY ControlLogix plc 1756-A10 ControlLogix 10 Slots Chassis

ALLEN BRADLEY ControlLogix plc 1756-A10 ControlLogix 10 Slots Chassis

Brand Name: AB
Model Number: 1756-A10
MOQ: 1
Price: Negotiation
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: In Stock
Detail Information
Place of Origin:
USA
Certification:
CE
Packaging Details:
New Original Box
Supply Ability:
In Stock
Highlight:

1756-A10 ControlLogix plc

,

ControlLogix 10 Slots Chassis

,

ALLEN BRADLEY ControlLogix plc

Product Description
Detailed Product Description
Brand: AB Type: PLC
Model: 1756-A10 Origin Of Country: USA
Series: SLC 500 Output Types:: N.O. Relay Contact
Lead Time: 3days Warranty: 1 Year
Highlight:

ethernet plc controllers

,

industrial automation using plc





ALLEN BRADLEY ControlLogix plc 1756-A10 ControlLogix 10 Slots Chassis





Product Description
Quick Details
Place of Origin:
Wisconsin, United States
Brand Name:
Allen Bradley
Model Number:
1756
Name:
1756-A10 ControlLogix plc i/o Modules
Weight:
4.082 lbs
Series:
PLC-5
Desc.:
allen bradley distributors locator
SER:
A B C D E
Type:
PLC
User Memory Words, Max:
100,000
Total I/O, Max:
3072
Number of Communication Ports (mode):
1756
Manufactuer:
Rockwell Automation



Description:


AB 1756-A10 10 Slot ControlLogix Chassis. The 1756-A10 chassis backplane provides a high-speed communication path between modules and distributes power to each of the modules within the chassis. Any ControlLogix module can be placed into any slot. Slot filler modules (1756-N2) are required to fill empty slots.

The 1756-A10 ControlLogix chassis are designed for horizontal mounting only. Number of Slots: 10; Backplane current, chassis/slot max @ 1.2V DC: 1.5 A/1.5 A; Backplane current, chassis/slot max @ 3.3V DC: 4 A/4 A; Backplane current, chassis/slot max @ 5.1V DC: 15 A/6 A; Backplane current, chassis/slot max @ 24V DC: 2.8 A/2.8 A; Power dissipation: 6.1 BTU/hr; Power consumption: 1.8 W. Dimensions (WxHxD): 483 x 169 x 145 mm (19.0 x 6.65 x 5.71 in.); Cabinet size (WxHxD), min: 762x 507 x 203 mm (30 x 20 x 8 in.); Weight, approx.: 1.45 kg (3.2 lb).



other model number

1756-A10 1756-L71 1756-IF8
1756-A13 1756-L72 1756-IF8I
1756-A17 1756-L73 1756-IG16
1756-A4 1756-N2 1756-IT16
1756-A7 1756-OA16 1756-L61
1756-CN2R 1756-OA8 1756-L62
1756-CN B 1756-OB16D 1756-L63
1756-CN BR 1756-OB16E 1756-L64
1756-DNB 1756-OB16I 1756-L65
1756-EN2T 1756-OB32 1756-PB75
1756-ENBT 1756-OB8 1756-RM2
1756-HSC 1756-OF4 1756-IF16
1756-IA16 1756-OF6CI 1756-IF6I
1756-IA16I 1756-OF6VI 1756-PA75R
1756-IA32 1756-OF8 1756-PB72
1756-IA8D 1756-OG16 1756-IB32
1756-IB16 1756-OW16I 1756-IC16
1756-IB16D 1756-PA72
1756-IB16I 1756-PA75






ALLEN BRADLEY ControlLogix plc 1756-A10 ControlLogix 10 Slots Chassis 0
