Panasonic FP0R series AFP0RF32CP PLC Programmable Logic Controller input 16, PNP output 16

Name: Panasonic FP0R series AFP0RF32CP PLC Programmable Logic Controller input 16, PNP output 16
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: AFP0RF32CP
Price: 285.00 USD
Availability: InStock

Brand Name:	Panasonic
Model Number:	AFP0RF32CP
MOQ:	1
Price:	Negotiation
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	In Stock

Detail Information

Product Description

Detail Information

Place of Origin:

Japan

Certification:

Packaging Details:

New Original Box

Supply Ability:

In Stock

Product Description

Detailed Product Description

Brand:	Panasonic	Model Number:	AFP0RF32CP
Country Of Origin:	Japan	Type:	PLC Programmable Logic Controller
Number Of Outputs And Type:	16 - Pulse (4), PWM (4), Solid State (8)	Expandable:	3 Modules Max
Voltage - Supply:	24VDC	Operating Temperature:	0°C ~ 55°C
Highlight:	ethernet plc controllers , industrial automation using plc

Panasonic FP0R series AFP0RF32CP PLC Programmable Logic Controller input 16, PNP output 16

Spec Detail

Item	Specifications
Product Number	AFP0RF32CP
Part Number	AFP0RF32CP

Performance specifications

Item	Specifications
Programming method / Control method	Relay symbol / Cyclic operation
Number of I/O points : No expansion (Control unit only)	32 points [Input : 16, Transistor output : 16]
Number of I/O points : With expansion 1 Same type of control and expansion units	Max. 128 points (Note: For the limitations while operating units, reter to the manual.)
Number of I/O points : With expansion 2 Mix type of relay and transistor units	Max. 128 points (Note: For the limitations while operating units, reter to the manual.)
Program memory	EEPROM (no backup battery required)
Program capacity	32 k steps
Number of instructions : Basic	110 approx.
Number of instructions : High-level	210 approx.
Operation speed : Up to 3,000 steps	Basic instructions : 0.08 μs min. Timer instructions : 2.2 μs min. High-level instructions : 0.32 μs (MV instruction) min.
Operation speed : 3,001st and later steps	Basic instructions : 0.58 μs min. Timer instructions : 3.66 μs min. High-level instructions : 1.62 μs (MV instruction) min.
Operation memory : Relay : Internal relay (R)	4,096 points
Operation memory : Relay : Timer / Counter (T / C)	1,024 points
Operation memory : Memory area : Data register (DT)	32,765 words
Operation memory : Memory area : Index register (IX, IY)	14 words (IO to ID)
Master control relay points (MCR)	256 words
Number of labels (JMP and LOOP)	256 labels
Differential points	Equivalent to the program capacity
Number of step ladder	1,000 stages
Number of subroutines	500 subroutines
Special functions : High speed counter	Single-phase: 6 points (50 kHz max. each) 2-phase: 3 channels (15 kHz max. each) (Note: For the limitations while operating units, reter to the manual.)
Special functions : Pulse output	4 points (50 kHz max. each) 2 channels can be controlled individually. (Note: For the limitations while operating units, reter to the manual.)
Special functions : PWM output	4 points (6 Hz to 4.8 kHz)
Special functions : Pulse catch input / interrupt input	Total 8 points (with high speed counter)
Special functions : Interrupt program	Input : 8 programs (6 programs for C10 only) / Periodic : 1 program / Pulse match : 4 programs/td>
Special functions : Periodical interrupt	In units of 0.5 ms : 0.5 ms to 1.5 sec. / In units of 10 ms : 10 ms to 30 sec.
Special functions : Constant scan	In units of 0.5 ms : 0.5 ms to 600 ms
Special functions : RS-232C port	One RS-232C port is mounted (3P terminal block) Transmission speed (Baud rate) : 2,400 to 115,200 bits/s, Transmission distance : 15 m 9.843 ft. Communication method : half duplex
Maintenance : Memory backup : Program and system register	Stored program and system register in EEPROM
Maintenance : Memory backup : Operation memory	Backup of the entire area by FeRAM (without the need for a battery)
Maintenance : Self-diagnostic function	Watchdog timer (690 ms approx.), Program syntax check
Maintenance : Real-time clock function	Not available
Maintenance : Other functions	Rewriting in RUN mode, Download in RUN mode (incl. comments), 8-character password setting, and Program upload protection

General specifications

Item	Specifications
Rated voltage	24 V DC
Operating voltage range	20.4 to 28.8 V DC
Allowed momentary power off time	10 ms (20.4 V DC or higher)
Operating temperature	0 to +55 ℃ 32 to +131 ℉
Storage temperature	-40 to +70 ℃ -40 to +158 ℉ (-20 ℃ to +70 ℃ -4 to +158 ℉ for T32 only)
Operating humidity	10 to 95% RH (at 25 ℃ 77 ℉, no condensation)
Storage humidity	10 to 95% RH (at 25 ℃ 77 ℉, no condensation)
Breakdown voltage (Detection current: 5 mA)	Input terminals - output terminals, Output terminals - power and functional ground terminals --- Transistor output : 500 V AC for 1 minute (Relay output : 1,500 V AC for 1 minute) / Input terminals - power and functional ground terminals, Functional ground terminal - power terminal --- Transistor output : 500 V AC for 1 minute (Relay output : 500 V AC for 1 minute) / Output terminals - output terminals (different common terminals) --- Relay output : 1,500 V AC for 1 minute
Insulation resistance (Test voltage: 500 V DC)	Input terminals - output terminals, input terminals - power and functional ground terminals, output terminals - power and functional ground terminals, functional ground terminal - power terminal --- Transistor output : 100 MΩ minimum (relay output : 100 MΩ minimum) / Output terminals - output terminals (different common terminals) --- Relay output : 100 MΩ minimum
Vibration resistance	5 to 9 Hz, single amplitude of 3.5 mm, 1 sweep/min; 9 to 150 Hz, constant acceleration of 9.8 m/s², 1 sweep/min; for 10 min each in X, Y, and Z directions
Shock resistance	147 m/s² or more , 4 times each in X, Y, and Z directions
Noise immunity	1,000 V (p-p) with pulse widths 50 ns and 1 μs (using a noise simulator)(Power supply terminal)
Operating environment	Free from corrosive gasses and excessive dust

Input specifications

Item	Specifications
Rated input voltage	24 V DC
Applied voltage range	21.6 to 26.4 V DC
Rated input current	2.6 mA approx. (at 24 V DC)
Input impedance	9.1 kΩ approx.
Input points per common	16 points / common
Min. ON voltage/Min. ON current	19.2 V / 2 mA
Max. OFF voltage/Max. OFF current	2.4 V / 1.2 mA
Response time : OFF→ON	20 μs or less * An input time constant (0.1 to 64 ms) can be set.
Response time : ON→OFF	Same as above
Insulation method	Photocoupler
Remark	Since the response time of X0 to X7 is very fast (for high-speed counter input) the FP0 happens to chattering noise as an input signal. To prevent this, it is recommended that the timer should be put in the ladder program.
