Rosemount 2088 Absolute and Gage Pressure Transmitter 2088G4S22A1B4M5 NEW

Name: Rosemount 2088 Absolute and Gage Pressure Transmitter 2088G4S22A1B4M5 NEW
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: 2088G4S22A1B4M5
Price: 210.00 USD
Availability: InStock

Brand Name:	Rosemount
Model Number:	2088G4S22A1B4M5

Detail Information

Product Description

Detail Information

Place of Origin:

OEM

Type:

Pressure Transmitter

Range:

0-4000PSI

Communication Protocol:

4-20 MA HART

Warranty:

1 Year

Highlight:

Rosemount 2088 Absolute Pressure Transmitter

Rosemount 2088 Gage Pressure Transmitter

Rosemount 2088 Pressure Transmitter

Product Description

Rosemount 2088 Absolute and Gage Pressure Transmitter 2088G4S22A1B4M5 NEW

Quick details

 Performance of 0.065% with High Accuracy option

 Lightweight, compact design for cost-effective installation

 Protocols available include 4-20 mA HART ® and 1-5 Vdc HART Low Power

 Absolute and gage pressure ranges up to 4,000 psi (276 bar)

 Rangeability of 50:1

Rosemount™ 2088 Gage and Absolute Pressure Transmitter

With the Rosemount 2088 Gage and Absolute Pressure Transmitter, you can keep on schedule with a

quick and easy-to-install solution. This transmitter features a Local Operator Interface (LOI) that has easy-

to-use menus and built-in configuration buttons, so you can commission the device on the spot without

complicated tools. This pressure transmitter is also available with manifolds and remote seals.

Proven reliability for gage and absolute applications

 Available protocols include 4-20 mA HART and 1-5 Vdc HART Low Power

 Fully configurable LCD display to display process variable, percent of range, and diagnostic messages

 Lightweight, compact design enables easy installation

 Choice of Stainless Steel or Alloy C-276 wetted materials

Unlock the value of devices with the Smart Wireless THUM ™ Adapter

 Gain access to field intelligence and improve quality, safety, availability, operations, and maintenance

costs

 Remotely manage devices and monitor health

 Enable new wireless measurement points

 Utilize existing loop power

Proven, reliable, and innovative DP Level technologies

 Connect to virtually any process with a comprehensive offering of process connections, fill fluids, direct

mount or capillary connections and materials

 Quantify and optimize total system performance with QZ option Instrument manifolds –quality,convenient,

and easy

 Designed and engineered for optimal performance with Rosemount transmitters

 Save installation time and money with factory assembly

 Offers a variety of styles, materials, and configurations

Specifications:

Rangedown	Up to 150:1
Communication Protocol	4-20 mA HART, WirelessHART®, FOUNDATION fieldbus, Profibus, 1-5 V Low Power HART
Measurement Range	Up to 2000psi (137,89 bar) Differential, Up to 2000psig (137,89 bar) Gage, Up to 4000psia (275,79 bar) Absolute
Process Wetted Material	316L SST, Alloy C-276, Alloy 400, Tantalum, Gold-plated Alloy 400, Gold-plated 316L SST
Diagnostics	Basic Diagnostics, Power Advisory Diagnostics
Certifications/Approval	SIL 2/3 certified to IEC 61508 by an independent 3rd party, NSF, NACE, hazardous location, see full specs for complete list of certifications

Certifications:

1. Certificate of Origin

2. Calibration Certificate

3. Material Traceability Certification

We also can offer these modeles:

Brand	Model	Condition
Rosemount	3051CD0A02A1AB1H2L4M5	New
Rosemount	3051CD1A02A1AB1H2L4M5	New
Rosemount	3051CD2A02A1AB1H2L4M5	New
Rosemount	3051CD3A02A1AB1H2L4M5	New
Rosemount	3051CD4A02A1AB1H2L4M5	New
Rosemount	3051CD5A02A1AB1H2L4M5	New
Rosemount	3051TG1A2B21A	New
Rosemount	3051TG3A2B21AB4	New
Rosemount	3051TG1A2B21AB4M5K5	New
Rosemount	3051TG5A2B21AB4M5E5	New
Rosemount	3051TG5A2C21AB4M5K5	New
Rosemount	3051TA1A2B21AB4M5K5	New
Rosemount	3051TA3A2B21AB4M5E5	New
Rosemount	3051TA3A2B21AB4M5I5	New

Rosemount	3051GP1A2B21AB4M5	New
Rosemount	3051GP3A2B21AB4M5K5	New
Rosemount	3051GP4A2B21AB4M5E5	New
Rosemount	3051GP5A2B21AB4M5I5	New
Rosemount	3051CG1A02A1AB1H2L4M5
Rosemount	3051CG1A02A1AB3H2L4M5
Rosemount	3051CG4A02A1AB1H2L4M5K5	New
Rosemount	3051CG4A02A1AB1H2L4M5I5	New
Rosemount	3051CG5A02A1AB3H2L4M5I5	New
Rosemount	3051CA1A02A1AB1H2L4M5	New
Rosemount	3051CA2A02A1AB1H2L4M5K5	New
Rosemount	3051CA4A02A1AB1H2L4M5E5	New
Rosemount	3051CA5A02A1AB1H2L4M5I5	New
Rosemount	3051CA3A02A1AB3H2L4M5K5	New
Rosemount	3051CA5A02A1AB3H2L4M5K5	New
Rosemount	3051CA1A02A1AB3H2L4M5E5	New
