Low Voltage Protection Devices
Created with Pixso.

Siemens 3SU Series Flat Head Circular Button Green 3SU1106-0AB40-1BA0 With Integrated LED

Siemens 3SU Series Flat Head Circular Button Green 3SU1106-0AB40-1BA0 With Integrated LED

Siemens 3SU Series Flat Head Circular Button Green 3SU1106-0AB40-1BA0 With Integrated LED

Brand Name: Siemens
Model Number: 3SU1106-0AB40-1BA0
Detail Information
Product Description
Detail Information
Place of Origin:
China
Model:
3SU1106-0AB40-1BA0
Light:
LED
Color:
Green
Diameter:
Aperture 22mm
Termination Type:
Tightening
Rated Insulation Voltage:
500V
Rated Working Current Of Contact:
10A (AC-12 230V), 6A (AC-15 230V)
Maximum Working Temperature:
+70℃
Minimum Working Temperature:
-25℃
Working Voltage:
220V AC
Highlight:

Siemens flat head circular button

,

3SU series flat head circular button

,

3SU1106-0AB40-1BA0 flat head circular button

Product Description

Siemens 3SU series flat head circular button green 3SU1106-0AB40-1BA0 with integrated LED

Product Name

Flat-head Plastic Push Button with Light

Mode

3SU1106-0AB40-1BA0

Product

Standard Switch

Warranty Period

1 year

Minimum Order Quantity

1 piece

Siemens 3SU Series Flat Head Circular Button Green 3SU1106-0AB40-1BA0 With Integrated LED 0


Flat - Nose Round Buttons with Light, of Instantaneous - Action Type and Integrated LED

Button Color

Product Order Number

Yellow

3SU1106-0AB30-1BA0

Green

3SU1106-0AB40-1BA0

Blue

3SU1106-0AB50-1BA0

White

3SU1106-0AB60-1BA0

Colorless

3SU1106-0AB70-1BA0

The Siemens 3SU1106 - 0AB40 - 1BA0 is a component within the SIRIUS ACT series, renowned for its reliability and functionality in industrial control systems. This illuminated push button complete unit is designed to meet the diverse needs of panel - mount applications, offering a combination of durability, easy operation, and clear indication.

Under the brand name SIRIUS ACT, Siemens offers a unique portfolio of pushbuttons and signaling devices with global product approvals in three modern design lines of rugged genuine metal and high-grade plastic.An innovative snap-on concept makes the task of installing a unit so easy that it can be done with one hand and without any special tools.Groove-free holes are adequate as mounting holes since full twist preventionis already integrated.Thanks to the high degree of protection throughout, the rugged devices are suitable for use in industry and outdoors. Even cleaning with a high-pressure jet is possible. Neither dust, oils, nor caustic solutions can interfere with reliable operation.As well as standard wiring, the devices can also be connected to the controller via PROFINET, AS-Interface or IO-Link. Doing so will help you to reduce wiring time and effort, minimize error sources and have more flexibility.The graphical Online Configurator provides convenient support when selecting and ordering individual devices, enclosures and labels.
