Top Shaft Oil Pump Outlet Filter Element TLX268A/20P Filter Cartridge TLX-268A/20

Product Description:

The outlet filter element TLX268A/20P of the top shaft oil pump is mainly used for filtering hydraulic system oil. During the use of hydraulic oil for 2000 hours, the oil will also carry a small amount of fine air bubbles in the flow, causing oxidation of the oil. The acidity produced by hydraulic oil oxidation will change the color of the oil, whether red or black, increasing its corrosiveness to metals. The oil sludge sediment generated after corrosion can block the small gaps in the hydraulic oil filter element, hydraulic oil radiator, and distributor valves. The filter element solves the pollution problem in oil filtration for repairing hydraulic systems.



Features:

(1) The hydraulic oil filter element series in power plants has a large flow rate per unit area;
(2) Uniform and precise filtration accuracy of filter pores;
(3) Good corrosion resistance, heat resistance, pressure resistance, and wear resistance;
(4) Hydraulic oil filter is suitable for low and high temperature environments; After cleaning, it can be reused without replacement.
(5) Good filtration performance and uniform surface filtration performance for filtration particle sizes ranging from 2-200um



Top shaft oil pump outlet filter element TLX268A/20P testing standard:
Test 1: ISO2941 ·· Verification of the anti rupture performance of filter cartridges
Test 2: ISO2942 ·· Determination of structural integrity of filter cartridges
Test Three: ISO2943 ·· Determination of Compatibility between Filter Element Materials and Liquids
Test 4: ISO3723 ·· End load test method for filter cartridges
Test 5: ISO3724 ·· Determination of fatigue characteristics of filter cartridges
Test 6: ISO3968 ·· Determination of differential pressure flow characteristics of filter cartridges
Test 7: ISO4572 ·· Filter Element Determination of Filtration Characteristics by Multiple Pass Method



filter element for power plant EH system WU-250X80 oil suction filter for power plant ion exchange resin filter element A911300

Technical Parameters:

 Power plant hydraulic oil filter series working medium: acid grease hydraulic oil emulsion water ethylene glycol
Material: Fiberglass filter paper-BN stainless steel woven mesh W
Working pressure: 21bar-210bar
Working temperature: -30 ℃~+110 ℃
Sealing material: fluororubber ring nitrile rubber
Filtering accuracy: from 1, 3, 6, 12, 25 μ M
Filter ratio: X ≥ 100
Structural strength: 1.0Mpa

Applications:

 1. Metallurgy: The hydraulic oil filter element series in power plants is used for filtering hydraulic systems of rolling mills and continuous casting machines, as well as filtering various lubrication equipment.
2. Petrochemical: separation and recovery of products and intermediate products in refining and chemical production processes, purification of liquids, purification of magnetic tapes, optical discs, and photographic films in manufacturing, and filtration of oilfield injection water and natural gas particles.
3. Textile: Purification and uniform filtration of polyester melt during drawing process, protective filtration of air compressor, and oil and water removal of compressed gas.
4. Electronics and pharmaceuticals: pre-treatment filtration of reverse osmosis water and deionized water, pre-treatment filtration of detergent and glucose.
5. Thermal power and nuclear power: purification of oil in lubrication systems, speed control systems, bypass control systems of gas turbines and boilers, purification of feedwater pumps, fans, and dust removal systems.
6. Various lifting and handling operations: from construction machinery such as lifting and loading to special vehicles for firefighting, maintenance, and handling, ship's cargo and anchor cranes, blast furnace and steelmaking equipment, ship locks, opening and closing devices for ship doors, lifting orchards and stages in theaters, various automatic conveyor lines, etc.
7. Various operational devices that require force, such as hydraulic presses, metal material die-casting, forming, rolling, rolling, stretching, and shearing equipment, plastic injection molding machines, plastic extruders and other chemical machinery, tractors, harvesters, and other agricultural and forestry machinery used for logging and mining, excavation equipment for tunnels, mines, and ground, steering gear for various ships, etc.
