ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot

ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot

  • ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
  • ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
  • ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
  • ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
  • ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
  • ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot
Product Details:
Place of Origin: UK
Brand Name: NORGREN
Model Number: SXE9575-A71-00/13J
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: contact
Delivery Time: 15 days
Payment Terms: TT
Supply Ability: 100unit / month
Contact Now
Detailed Product Description
MODEL: SXE9575-A71-00-13J Material: Cast Aluminium
Flow Rate: 4400 L/min Size: 22mm ISO #3
Brand: Norgren Voltage: 24Vdc
Standard: ISO 5599-1 Pressure: 16.0 Bar
High Light:

ISO Pneumatic Solenoid Valve

,

Magnetic Pilot Pneumatic Solenoid Valve

,

16.0 Bar Water Solenoid Valve

ISO STAR solenoid valve SXE9575-A71-00/13J control part IMI NORGREN cast aluminium



ISO Star electric control valve - solenoid pilot

characteristic

·The valve core and valve sleeve with special coating metal seal can work without fault and long life

·Iso#1 and iso#2 valves with integral flow regulating valve

·Standard low power solenoid with manual control

·Rich base plate and accessories



Product: sxe9575-a71-00-13j

Flow:4400 l/min

ISO size: ISO #3

drive: forty-one thousand and thirty-one

Standard: ISO 5599-1; VDMA 24 345

Brand: ISO*STAR

voltage:  24Vdc

junction box type: 22mm industrial standard





Medium:  Compressed air 41031

drive Start: : Electric control / air spring

voltage: 24Vdc

maximum working pressure:  16.0 bar

working pressure:  1 ... 10 bar

working temperature: -15 ... 80 °C

ISO size:  ISO #3

electrical connection:  22mm industrial standard

pilot:  Inside

manual control: VDMA 24 345 ; Locking device

protection grade: IP65

Standard: ISO 5599-1

flow: 4400 l/min

junction box type:  22mm industrial standard

coil power: 2.0 Watt/VAC

material - nut and screw: Galvanized steel Nitrile rubber; Heat resistant seal

Seal: Body:  Die cast aluminum

valve core and sleeve: Anodized aluminum

Brand:ISO*STAR





ISO Pneumatic Solenoid Valve SXE9575-A71-00/13J 16.0 Bar Magnetic Pilot 0
