| Place of Origin: | China |
| Brand Name: | RG |
| Model Number: | ZSGQ2 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Packaging Details: | Wooden box |
| Delivery Time: | Within 15days |
| Payment Terms: | T/T |
| Supply Ability: | 1000pcs / month |
| Material: | Stainless Steel | Pressure: | High Pressure,Medium Pressure,Low Pressure |
|---|---|---|---|
| Power: | Pneumatic | Temperature Of Media: | Medium Temperature,High Temperature,Normal Temperature |
| Media: | Water,oil | Product Name: | Electric Valve Actuators |
| High Light: | 200mm Cylinder Electric Valve Actuators,Electric Valve Actuators 660mm Trip,0.5MPa Electronic Regulator Regulating Valve |
||
ZDLN electronic regulator regulating valve
1, use
Used in power plant boiler fuel system to discharge gate mouth opened and closed.
2, the principle of work
Powered by compressed air energy, accept the switch signal, the output linear displacement, drive is accused by a certain thrust mechanism.
3, the characteristics
Big output thrust, with buffer structure, action is stable and reliable.
4, main technical parameters
| Input air source pressure | 0.5MPa | type | Output pressure (N) | Cylinder inner dia (mm) | A1 | A2 | B1 | B2 | |
| trip | 660mm | ||||||||
| Full trip time | Empty load | 30s | 200X660 | 14137 | ￠200 | 290 | 360 | 174 | 230 |
| Full load | 40s | 250X660 | 22088 | ￠250 | 340 | 410 | 224 | 280 | |
| Environment temperature | -20～100℃ | 300X660 | 31800 | ￠300 | 390 | 460 | 274 | 330 | |
