Place of Origin: | China |
Brand Name: | OEM |
Model Number: | JM-C-3KA |
Minimum Order Quantity: | 1 set |
---|---|
Packaging Details: | Wooden box packing |
Delivery Time: | 15 days after signing the contract |
Payment Terms: | T/T |
Supply Ability: | 1000sets |
Outline Dimension: | φ35×84(mm) | Current Output: | 4~20mA |
---|---|---|---|
Switching Value: | DC27V/2A Or AC250V/5A | Power Supply Voltage: | DC+24V |
Working Temperature: | -10~65℃ | Relative Humidity: | ≤95% |
High Light: | 20mA Integrated Bearing Vibration Transmitter,DC27V Integrated Bearing Vibration Transmitter,100μm Protection Vibration Monitor |
JM-B-35 Integrated bearing vibration transmitter
Sytem description
• Bearing vibration monitoring
• two wire system
• Integration of the sensor and transmitter
• waterproof of connector design
Technical parameters
Order No. | Description |
Measure range | To the order guide |
Outline dimension | φ35×84(mm) |
Current output | 4~20mA(load≤1KΩ) |
Switching value | DC+24V |
Power supply voltage |
Working temperature : -10~65℃, Relative humidity : ≤95% |
Order Guide:
Order No. | The selection of sensor A | The selection of range B | Expand C | Order No. |
JM-B-35- Integrated bearing vibration transmitter
|
1: 10.0mm/s 2: 20.0mm/s* 3: 40.0mm/s 4: 50.0mm/s 5: 100μm 6: 200μm 7: 400μm 8: 500μm n: special requirements |
1: M10×1.0×10(L) 2: M10×1.5×10(L)* n: special requirements |
1: 2m metal shielding 2: 5m non metal shielding 3: 10m metal shielding 4: 2m non metal shielding * 5: 5m metal shielding 6: 10mmetal shielding n: special requirements |
0: NO |
Note :The specific requirements should be provided for special model selection
