Adjustable High Performance Ignition System Intensifire

China Adjustable High Performance Ignition System Intensifire supplier
Adjustable High Performance Ignition System Intensifire supplier Adjustable High Performance Ignition System Intensifire supplier Adjustable High Performance Ignition System Intensifire supplier

Large Image :  Adjustable High Performance Ignition System Intensifire

Product Details:

Place of Origin: China
Brand Name: OEM
Model Number: XDZ series

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Packaging Details: Wooden box packing
Payment Terms: T/T
Supply Ability: 500
Contact Now
Detailed Product Description

Adjustable High Performance Ignition System Intensifire



Applications:

  • Ignition of medium-sized oil burners in industrial furnaces and boilers



Standard type soft rod explosion proof high energy igniting gun XDZ-1R-l/d B  600 ~ 1400V High energy ignition device



1,Product Description: use from ignition cable input voltage DC discharge in high energy electric spark forming head.



2,Technical advantages and honor- Low ignition voltage;- Good temperature resistance;- Safety and reliability, strong ability to resist pollution.

used for XDH high-energy ignition device assembly.



Specifications:

Brief introduction

1,Product Description: use from ignition cable input voltage DC discharge in high energy electric spark forming head.
2,Technical advantages and honor
- Low ignition voltage;
- Good temperature resistance;
- Safety and reliability,  strong ability to resist pollution

3,Applications:

As XDH high-energy ignition device assembly.





Product model and series

1. Product series

Sr.

Model

Description

1

XDZ-1-l/d

Standard type hard rod high energy ignition gun

2

XDZ-1-l/d B

Standard type hard rod explosion-proof high-energy igniting gun

3

XDZ-1-l/d K

Standard type hard gun handle high energy ignition gun

4

XDZ-1R-l/d

Standard type soft rod high energy ignition gun

5

XDZ-1R-l/d B

Standard type soft rod explosion-proof high-energy igniting gun

6

XDZ-2-l/d

Non standard hard rod high energy ignition gun

7

XDZ-2-l/d B

Non standard hard rod explosion-proof high-energy igniting gun

8

XDZ-2R-l/d

Non standard soft rod high energy ignition gun

9

XDZ-2R-l/d B

Non standard soft rod explosion-proof high-energy igniting gun

10

XDZ-3-l/d

Special electric nozzle high-energy igniting gun

11

XDZ-3-l/d B

Explosion proof special electric nozzle high-energy igniting gun

12

XDZ-4-l/d B

The hard rod high clearance point guns

【Note 】
①In the table type codelis igniting gun length, in order to unit mm;
②In the table d is igniting gun diameter ,there are 14mm,16mm,18mm series to choose;
③ according user demanding to special design and produce.


1. basic configuration:(leave)

2. Performance parameters

Various types of ignition performance parameters:

Parameter name

Unit

Data

Starting ignition voltage

VDC

600~1400

center electrode resistance

Ω

≤0.1

firing end long-term temperature

≤800

firing end short-time (<5min) temperature resistance

1250




3. Outline and mounting dimensions




Adjustable High Performance Ignition System Intensifire
Drawing 3-1,XDZ-1- l/18 Standard type hard rod high energy ignition gun(L≤1000mm)



Adjustable High Performance Ignition System Intensifire
Drawing 3-2,XDZ-1-l/18 Standard type hard rod high energy ignition gun(L>1000mm)


Adjustable High Performance Ignition System Intensifire
Drawing 3-3,XDZ-1-l/d B Standard type hard rod explosion-proof high-energy igniting gun



Adjustable High Performance Ignition System Intensifire
Drawing 3-4,XDZ-1- l/18 K Standard type hard gun handle high energy ignition gun



Adjustable High Performance Ignition System Intensifire
Drawing 3-5,XDZ-1R-l/18 Standard type soft rod high energy ignition gun



Adjustable High Performance Ignition System Intensifire
3-6,XDZ-3 Catalytic plug ignition gun



Adjustable High Performance Ignition System Intensifire
Drawing 3-7,XDZ-4-l/d hard rod high pressure gap ignition gun
